Omron XS3F-M322-305-R

Technical specifications

Manufacturer

Omron

Manufacturer part no.

XS3F-M322-305-R

Type

M8 or M12 connector

Application

Connection of a compatible sensor or actuator to field wiring.

Used with

A device connector with matching size, gender, keying and pin assignment, plus the appropriate receiving circuit.

Usage

Cable with connector

Connector 1

M8 right-angle socket

Connector 2

Open ends

Number of pin contact

3

Cable specifications

PVC

Cable length

5 m

Features

Robotic

Color

Black

Color cover

Black

Material nut

Brass

LED indicator

No

Technical documents (1)

• Omron M8-CONNECTORS-AND-CORDSETS specifications and ordering table

Key features

• M8 right-angle socket
• 3 contacts
• PVC
• Robotic

About the Omron XS3F-M322-305-R

Connector orientation, cable length and jacket material distinguish ordering variants. Confirm the pin-to-wire allocation and load requirements before connecting a sensor or actuator.

What is the XS3F-M322-305-R used for?

Connection of a compatible sensor or actuator to field wiring.

Lifecycle and successor

To be confirmed.

Before you order

What to photograph or confirm so the right unit is quoted.

Confirm the complete ordering code, connector size and number of contacts. Match male/female interface, straight/right-angle orientation, keying and pin assignment. Check voltage/current ratings and ingress-protection conditions for the mated assembly. For field assembly, verify termination method and cable diameter; for cordsets, verify length and jacket requirements. State quantity and required delivery date, and provide the mating-device reference if available.
