Allen-Bradley 1747-SN

Technical specifications

Manufacturer

Allen-Bradley

Manufacturer part no.

1747-SN

Type

Communication module

Application

Communication module

Used with

SLC 500 1746 chassis

Backplane Current Consumption

600 mA @ 5V dc

Operating Temperature

+32°F to 140°F (0°C to +60°C)

Storage Temperature

-40°F to 185°F (-40°C to +85°C)

Humidity

5 to 95% without condensation

Noise Immunity

NEMA Standard ICS 2-230

Isolation

Comm Circuits:500v DC,

Module Interfaces

Remote I/O scanner

Number Of Channels

4

Technical documents (1)

• Rockwell Automation user manual 1747-UM013

Key features

• Remote I/O scanner module interface
• Provides four channels
• Draws 600 mA at 5V dc from the backplane
• Operates from 0°C to +60°C
• Comm circuit isolation of 500V DC

About the Allen-Bradley 1747-SN

The 1747-SN is the SLC remote I/O scanner module, with four channels, now discontinued. It draws 600 mA at 5V dc from the backplane, and comm circuit isolation is 500V DC. It works from 0°C to +60°C, is stored at -40°C to +85°C, and takes 5 to 95% humidity without condensation (user manual 1747-UM013). The 5069-AENTR is named by the maker as the successor (Engineering Replacement).

What is the 1747-SN used for?

It lets an SLC 500 controller scan remote I/O over its four channels. Noise immunity is to NEMA Standard ICS 2-230.

Lifecycle and successor

Discontinued (Rockwell Automation lifecycle status, checked 25 October 2026).

OEM successor: 5069-AENTR

Before you order

What to photograph or confirm so the right unit is quoted.

Read the catalog number 1747-SN, the series letter and the firmware revision from the label. Send us a photo of the label and we confirm the match before we quote.
