Allen-Bradley 1756-A10

Technical specifications

Manufacturer

Allen-Bradley

Manufacturer part no.

1756-A10

Type

Chassis

Application

ControlLogix chassis

Used with

1756 ControlLogix modules

Backplane current, chassis/slot max @ 1.2V DC

1.5 A/–

Backplane current, chassis/slot max @ 3.3V DC

4 A/4 A

Backplane current, chassis/slot max @ 5.1V DC

15 A/6 A

Backplane current, chassis/slot max @ 24V DC

2.8 A/2.8 A

Power dissipation, max

5 W

Isolation voltage

Determined by installed power supply and modules

Mounting method

Only horizontal

Cabinet size (HxWxD), min

50.8 x 71.1 x 20.3 cm (20 x 28 x 8 in.)

Weight, approx

1.45 kg (3.2 lb)

Location

Panel

Wire size

Functional earth ground - 8.3 mm2 (8 AWG) solid or stranded copper wire rated at 90 °C (194 °F) or greater, Protective earth ground - 2.1 mm2 (14 AWG) solid or stranded copper wire rated at 90 °C (194 °F) or greater

North American temperature code

T5 (Series B), T4 (Series C)

Enclosure type rating

None (open-style)

Technical documents (1)

• Rockwell Automation technical data 1756-TD006

Key features

• 10 slot ControlLogix chassis for panel location
• Backplane current up to 15 A at 5.1V DC
• Maximum power dissipation of 5 W
• Open-style enclosure with no enclosure type rating
• Approximate weight of 1.45 kg (3.2 lb)

About the Allen-Bradley 1756-A10

The 1756-A10 is a 10 slot ControlLogix chassis for panel mounting, horizontal only (technical data 1756-TD006). Backplane current is 15 A per chassis and 6 A per slot at 5.1V DC, and 4 A per chassis and per slot at 3.3V DC. It dissipates up to 5 W and weighs approximately 1.45 kg (3.2 lb).

What is the 1756-A10 used for?

It holds a power supply, controller and up to nine more modules in a ControlLogix system, carrying 1.2V, 3.3V, 5.1V and 24V DC on its backplane. Isolation voltage depends on the installed power supply and modules. The minimum cabinet size is 50.8 x 71.1 x 20.3 cm (20 x 28 x 8 in.).

Lifecycle and successor

Active (Rockwell Automation lifecycle status, checked 24 October 2026).

Before you order

What to photograph or confirm so the right unit is quoted.

Read the catalog number 1756-A10, the series letter and the firmware revision from the label. Send us a photo of the label and we confirm the match before we quote.
