Allen-Bradley 5094-IB16

Technical specifications

Manufacturer

Allen-Bradley

Manufacturer part no.

5094-IB16

Type

Digital input module

Application

Distributed I/O

Used with

5094 FLEX 5000 I/O system

On-state voltage range

10…32V DC

On-state current, min

2 mA @ 10V DC

On-state current, nom

6 mA @ 24V DC

On-state current, max

8 mA @ 32V DC

Off-state voltage, max

5V DC

Off-state current, max

1.5 mA

Module inrush current, max

250 mA peak (decaying to 37% in 22 ms, without activation)

Input delay time (screw to backplane), max

100 µs @ 25 °C (77 °F)

Input drift over temperature span

±300 ns/ °C (±166.6 ns/ °F) from -40…+70 °C (-40…+158 °F)

Input min pulse width

80 µs

Input filter time

Hardware delay: 98 µs + filter time, User-selectable filter time: 0…50 ms, Hardware delay: 98 µs + filter time, User-selectable filter time: 0…50 ms

Reverse polarity protection

Yes

Overvoltage protection, max

36V (fuse protected, non-replaceable)

Pulse and period measurements

Not supported

Simple counters

0 - f = 5000 Hz (inv period 0.2 ms) max, Channel 0…7 only

CIP Sync™

Transport clock, and slave only ordinary clock

Pulse latching

Supported

Events

Four events supported (triggered by any input or simple counters)

Inputs

16 channels (1 group of 16), sinking

Voltage category

12/24V DC sink

Backplane Power (BP) voltage

15V DC

Backplane Power (BP) current, max

80 mA

Sensor Actuator Power (SA) voltage range

18…32V DC

Sensor Actuator Power (SA) current, max

8 mA per channel 135 mA per module (128 mA + 7 mA for SA power detection)

Power dissipation, max

3.5 W

Technical documents (1)

• Rockwell Automation technical data 5094-TD001

Key features

• 16 sinking channels in one group of 16
• User-selectable input filter time of 0 to 50 ms
• Reverse polarity protection on the inputs
• Four events triggered by any input or simple counters
• Mechanical keying or electronic keying via programming software

About the Allen-Bradley 5094-IB16

The 5094-IB16 is a FLEX 5000 16 point digital input module. Its 16 sinking channels sit in one group, 12/24V DC, with an on-state range of 10…32V DC. Input delay is 100 µs maximum at 25 °C, and the filter time is selectable from 0…50 ms. It works from -40 °C to +70 °C (technical data 5094-TD001).

What is the 5094-IB16 used for?

It brings 16 DC signals into a FLEX 5000 I/O node, drawing up to 80 mA of 15V DC backplane power. Channels 0 to 7 handle pulse latching, four events and simple counters up to 5000 Hz. Field devices are powered from Sensor Actuator power at 18…32V DC.
