Advantech AQD-SD4U8GN32-SE

Technical specifications

Manufacturer

Advantech

Manufacturer part no.

AQD-SD4U8GN32-SE

Type

Memory module

Application

Industrial PCs and embedded boards

Used with

Boards and systems that take DDR4 SO-DIMMs

Manufacturer

Advantech

Capacity

8 GB

Chip Manufacturer

SAMSUNG

Chip Organization

1 G x 8

Rank

1 Rank

Interface

260 pin

Frequency

3200 Mhz

Voltage

1.2 V

PCB Height

1.18"

Feature

Unbuffered

Operating Temperature

0 ~ 85°C (32 ~ 185°F)

Technical documents (1)

• Advantech data sheet AQD-SD4U8GN32-SE

Key features

• 8 GB DDR4 at 3200 MHz
• 260-pin SO-DIMM, unbuffered (non-ECC)
• Single rank, Samsung 1G x 8 chips
• 1.2 V, 1.18-inch PCB
• Operating temperature 0 to 85 °C

About the Advantech AQD-SD4U8GN32-SE

The Advantech AQD-SD4U8GN32-SE is an 8 GB DDR4 SO-DIMM for industrial boards and PCs. Advantech gives it as 260-pin, unbuffered, 3200 MHz at 1.2 V, single rank with Samsung chips in a 1G x 8 organisation, on a 1.18-inch PCB, for 0 to 85 °C. Advantech lists anti-sulphurisation resistance and 30-microinch gold plating on the contacts.

What is the AQD-SD4U8GN32-SE used for?

It is the memory for boards and systems that take DDR4 SO-DIMMs, such as Advantech's SOM modules and AIMB motherboards, where a tested, identical module avoids compatibility problems.

Lifecycle and successor

Active.

Before you order

What to photograph or confirm so the right unit is quoted.

Read the order number from the module label (AQD-SD4U8GN32-SE). Check the board's supported memory list for DDR4-3200 SO-DIMM before ordering.
