Advantech FPM-215-R8AE

Technical specifications

Manufacturer

Advantech

Manufacturer part no.

FPM-215-R8AE

Type

Industrial monitor

Application

Machine and control-cabinet operator displays

Used with

PCs with HDMI, DisplayPort or VGA output

Ingress Protection

Front Panel IP66

Operating Temperature

0~50 °C (32~122 °F)

Storage Humidity

10~95% RH (non-condensing)

Storage Temperature

-20~60 °C (-4~140 °F)

Vibration Protection

1 Grms, random

Certification

CB, UL, CE, FCC Class A, CCC, BSMI

OS Support

Microsoft® Windows Vista, Microsoft® Windows 7, Microsoft® Windows 8,Microsoft® Windows XP, Microsoft® Windows XPe, Microsoft® Windows CE, Linux,Microsoft® Windows 10 LTSB

Power Consumption

15 W + 20%

Power Input

12 VDC

Video Port

HDMI, DP, VGA

Power Connector

1 x Lockable DC Jack

Backlight Life (hrs)

70,000

Display Size

15"

Luminance (cd/m2)

300

Max. Resolution

1024 x 768

Viewing Angle (H/V°)

176/176

Dimension (W x H x D)

383.2 x 307.3 x 53.20 mm

Enclosure

Die cast magnesium alloy, Die-casting aluminum

Mounting

Stand, Wall, VESA, Panel

Weight (Net)

4.6 kg (10.14 lb)

Touch Type

5-wire resistive

Technical documents (1)

• Advantech data sheet FPM-215

Key features

• 15-inch XGA TFT LCD, 1024 x 768, 300 cd/m²
• 5-wire resistive touch, anti-glare tempered glass
• HDMI, DisplayPort and VGA inputs
• IP66 front panel, die-cast aluminium chassis
• Stand, wall, VESA or panel mounting

About the Advantech FPM-215-R8AE

The Advantech FPM-215-R8AE is a 15-inch industrial monitor with a 1024 x 768 TFT LCD at 300 cd/m² and 5-wire resistive touch. It has no computer inside: it takes the picture from a PC over HDMI, DisplayPort or VGA. Advantech gives it an IP66 front panel, a 70,000-hour backlight, a 12 V DC input with a lockable jack, 0 to 50 °C operation and 383.2 x 307.3 x 53.2 mm. Other FPM-215 order numbers on the same page differ in version and region.

What is the FPM-215-R8AE used for?

It is the operator screen of a machine or control cabinet driven by a separate industrial PC, mounted in a panel cut-out or on a VESA arm.

Lifecycle and successor

Active.

Before you order

What to photograph or confirm so the right unit is quoted.

Read the order number from the label on the back (FPM-215-R8AE). For a panel-mount replacement, check the cut-out size against Advantech's drawing.
