Mitsubishi Electric FX5-4DA

Technical specifications

Manufacturer

Mitsubishi Electric

Manufacturer part no.

FX5-4DA

Type

Analog output module

Application

I/O module

Used with

MELSEC iQ-F FX5 CPU modules

Applicable Controller

MX Controller MX-F model *1

Applicable CPU module

FX5UJ CPU module: From first production; FX5U CPU module: Ver. 1.050 or later; FX5UC CPU module*: Ver. 1.050 or later; * FX5-CNV-IFC or FX5-C1PS-5V is required to connect to the FX5UC CPU module.

Applicable engineering tool, GX Works3

FX5UJ CPU module: Ver. 1.060N or later; FX5U CPU module: Ver. 1.040S or later; FX5UC CPU module: Ver. 1.040S or later

Number of occupied I/O points

8 points

Mass (weight)

Approx. 0.2 kg

No. of output points

4 points (4 channels)

Digital input

16-bit signed binary (-32768 to +32767)

Analog output voltage

-10 to +10 V DC (external load resistance value 1 k to 1 MΩ)

Analog output current

0 to 20 mA DC (external load resistance value 0 to 500 Ω)

Conversion speed

80 μs/ch

Isolation method

Between output terminal and PLC: Photocoupler; Between output channels: Non-isolation

Output characteristics, resolution, Analog output range (Voltage), 0 to 10 V

Digital output value: 0 to 32000; Resolution: 312.5 μV

Output characteristics, resolution, Analog output range (Voltage), 0 to 5 V

Digital output value: 0 to 32000; Resolution: 156.3 μV

Output characteristics, resolution, Analog output range (Voltage), 1 to 5 V

Digital output value: 0 to 32000; Resolution: 125 μV

Output characteristics, resolution, Analog output range (Voltage), -10 to +10 V

Digital output value: -32000 to +32000; Resolution: 312.5 μV

Output characteristics, resolution, Analog output range (Voltage), User range setting

Digital output value: -32000 to +32000; Resolution: 312.5 μV; Maximum resolution in the user range setting.

Output characteristics, resolution, Analog output range (Current), 0 to 20 mA

Digital output value: 0 to 32000; Resolution: 625 nA

Output characteristics, resolution, Analog output range (Current), 4 to 20 mA

Digital output value: 0 to 32000; Resolution: 500 nA

Output characteristics, resolution, Analog output range (Current), User range setting

Digital output value: -32000 to +32000; Resolution: 500 nA; Maximum resolution in the user range setting.

Accuracy (accuracy for the full scale of the analog output value)

Ambient temperature 25±5℃: Within ±0.1% (voltage ±20 mV, current ±20 μA); Ambient temperature 0 to 55℃: Within ±0.2% (voltage±40 mV, current ±40 μA); Ambient temperature -20 to 0℃: Within ±0.3% (voltage±60 mV, current ±60 μA)

External power supply, Power supply voltage

24 V DC +20%, -15%

External power supply, Allowable instantaneous power failure time

Operation continues when the instantaneous power failure is shorter than 5 ms.

External power supply, Current consumption

150 mA

Internal power supply, Power supply voltage

5 V DC

Internal power supply, Current consumption

100 mA

Technical documents (1)

• Mitsubishi Electric specification database, FX5-4DA

Key features

• Number of occupied I/O points: 8 points
• No. of output points: 4 points (4 channels)
• Digital input: 16-bit signed binary (-32768 to +32767)
• Analog output current: 0 to 20 mA DC (external load resistance value 0 to 500 Ω)
• Conversion speed: 80 μs/ch

About the Mitsubishi Electric FX5-4DA

The Mitsubishi Electric FX5-4DA is a MELSEC iQ-F analogue output module. Mitsubishi Electric's overview: Spring clamp terminal block type; Analog output: 4 ch. Mitsubishi Electric lists it as on sale.

What is the FX5-4DA used for?

The FX5-4DA connects to a MELSEC iQ-F FX5 CPU and adds analogue output channels the CPU reads or writes each cycle.

Lifecycle and successor

Active.

Before you order

What to photograph or confirm so the right unit is quoted.

Check the model name FX5-4DA on the rating plate, with the serial number and function version. Send us a photo of the rating plate and we will confirm the details before quoting.
