Mitsubishi Electric Q12PRHCPU

Technical specifications

Manufacturer

Mitsubishi Electric

Manufacturer part no.

Q12PRHCPU

Type

MELSEC-Q CPU module

Application

PLC controller

Used with

MELSEC-Q base units

Control method

Stored program cyclic operation

I/O control mode

Refresh mode; (The direct access input/output is available by specifying the direct access input/output (DX, DY).)

Programming language, Sequence control language

Relay symbol language, logic symbolic language, MELSAP3 (SFC), MELSAP-L, function block and structured text (ST)

Programming language, Process control language

FBD for process control

Processing speed, Sequence instruction, LD X0

34 ns

Processing speed, Sequence instruction, MOV D0 D1

102 ns

Processing speed, Redundant function, Tracking execution time (increased scantime)

Device memory 48k words: 10ms; Device memory 100k words: 15ms

Constant scan

0.5...2000 ms (setting is available in increments of 0.5 ms by parameter)

Program capacity

124K steps (496K bytes)

Memory capacity, Program memory (drive 0)

496K bytes

Memory capacity, Memory card (RAM) (drive 1)

Size of the installed memory card (2M bytes max.)

Memory capacity, Memory card (ROM) (drive 2)

Size of the installed memory card (Flash card: 4M bytes max., ATA card: 32M bytes max.)

Memory capacity, Standard RAM (drive 3)

256K bytes

Memory capacity, Standard ROM (drive 4)

496K bytes

Number of I/O device points

8192 points (X/Y0...1FFF)

Number of I/O points

4096 points (X/Y0...FFF)

No. of device tracking words

Maximum 100 k words

RUN/PAUSE contact

One contact can be set up in X0 to X1FFF for each of RUN and PAUSE.

Clock function

Year, month, date, hour, minute, second, and day of week (automatic leap year detection); Accuracy: -3.20...+5.27 s (TYP. +2.07 s)/d at 0 ˚C; Accuracy: -2.77...+5.27 s (TYP. +2.22 s)/d at 25 ˚C; Accuracy: -12.14...+3.65 s (TYP. -2.89 s)/d at 55 ˚C

Allowable momentary power failure time

The time differs depending on the power supply module used.

Internal current consumption (5 V DC)

0.89 A

External dimensions, Height

98 mm

External dimensions, Width

55.2 mm

External dimensions, Depth

89.3 mm

Weight

0.30 kg

Technical documents (1)

• Mitsubishi Electric specification database, Q12PRHCPU

Key features

• Program memory: 496K bytes
• Current consumption (5 V DC): 0.89 A
• Weight: 0.30 kg

About the Mitsubishi Electric Q12PRHCPU

The Mitsubishi Electric Q12PRHCPU is a MELSEC-Q CPU module. Mitsubishi Electric's overview: Number of I/O points: 4096, I/O device points: 8192, program capacity: 124K steps, basic operation processing speed (LD X0): 34 ns, program memory capacity: 496K bytes, external interface: USB/RS-232, with memory card interface, process control language supported, redundant function. Mitsubishi Electric lists it as discontinued since 2022/09, with repair support until 2029/09. Mitsubishi Electric names the R16PCPU as its replacement model.

What is the Q12PRHCPU used for?

The Q12PRHCPU runs the control program on a MELSEC-Q base unit, working with the I/O, intelligent function and network modules on the base.

Lifecycle and successor

Discontinued.

OEM successor: R16PCPU

Before you order

What to photograph or confirm so the right unit is quoted.

Check the model name Q12PRHCPU on the rating plate, with the serial number and function version. Send us a photo of the rating plate and we will confirm the details before quoting.
