Omron NX-AD4204

Technical specifications

Manufacturer

Omron

Manufacturer part no.

NX-AD4204

Type

Analog input module

Application

I/O module

Used with

NX-series controllers and NX bus couplers

I/O system

NX I/O Bus

Type of module

Analog I/O

Number of analog inputs

8

Linear analog input type

4 to 20 mA

Resolution of the analog inputs

13 Bit

Input circuit type

Differential

Conversion time

2 ms/unit

Signal processing

Free running

I/O connection type

Push-in

Number of I/O connectors

1

Degree of protection (IP)

IP20

Height

104.5 mm

Width

12 mm

Depth

80.1 mm

Weight

70 g

Technical documents (1)

• Omron product page NX-AD4204

Key features

• Signal processing: Free running
• Degree of protection (IP): IP20
• Number of I/O connectors: 1
• Size 104.5 mm high, 12 mm wide, 80.1 mm deep

About the Omron NX-AD4204

The Omron NX-AD4204 is an NX analogue input unit. Omron describes it as: 8 Analog Inputs, 4 to 20 mA differential, resolution 1:8000, 250 µs/ch, screwless push-in connector, 12 mm wide. Its specification table gives 8 analogue inputs, 13 Bit input resolution and push-in connection. Omron's European product page carries no end-of-production notice for it.

What is the NX-AD4204 used for?

The NX-AD4204 slots onto the NX I/O bus next to an NX controller or bus coupler, carrying its analogue input signals to and from the machine.

Lifecycle and successor

Active.

Before you order

What to photograph or confirm so the right unit is quoted.

Check the model number NX-AD4204 on the unit's label, with its lot number. Send us a photo of the label and we will confirm the details before quoting.
