Omron NX-OD3268

Technical specifications

Manufacturer

Omron

Manufacturer part no.

NX-OD3268

Type

Digital output module

Application

I/O module

Used with

NX-series controllers and NX bus couplers

I/O system

NX I/O Bus

Type of module

Digital I/O

OFF/ON delay

0-0 ms

Number of digital outputs

4

Digital output type

PNP

Permitted voltage at output

15.0-28.8 V

Output current

2 A

Connection method

2-wire, 3-wire

Signal processing

Free running, Standard speed, Synchronous

I/O connection type

Push-in

Number of I/O connectors

1

Number of IOV (V+) terminals

6

Number of IOG (V-) terminals

6

Degree of protection (IP)

IP20

Height

106 mm

Width

12 mm

Depth

80 mm

Weight

70 g

Technical documents (1)

• Omron product page NX-OD3268

Key features

• Signal processing: Free running, Standard speed, Synchronous
• OFF/ON delay: 0-0 ms
• Connection method: 2-wire, 3-wire
• Degree of protection (IP): IP20
• Number of I/O connectors: 1

About the Omron NX-OD3268

The Omron NX-OD3268 is an NX digital output unit. Omron describes it as: 4 Digital Outputs, Standard speed, PNP 24 VDC, 2 A/point, 8 A/NX unit, screwless push-in connector, 12 mm wide. Its specification table gives 4 digital outputs, PNP outputs and 2 A output current. Omron's European product page carries no end-of-production notice for it.

What is the NX-OD3268 used for?

The NX-OD3268 slots onto the NX I/O bus next to an NX controller or bus coupler, carrying its digital output signals to and from the machine.

Lifecycle and successor

Active.

Before you order

What to photograph or confirm so the right unit is quoted.

Check the model number NX-OD3268 on the unit's label, with its lot number. Send us a photo of the label and we will confirm the details before quoting.
