Image is for illustrative purposes only. Please refer to product description.
- Manufacturer
- Allen-Bradley
- Manufacturer part number
- 1769-SDN
- Product family
- CompactLogix and 1769 Compact I/O Communication Modules
- Technical datasheet
- Data sheet
Specifications
| Attribute | Value |
|---|---|
| Type | DeviceNet scanner module |
| Manufacturer lifecycle | Discontinued |
| OEM successor | 1788-EN2DNR |
| Depth | 87mm, 3.43" |
| Conducted RF immunity | 10V rms with 1 kHz sine-wave 80% AM from 150 kHz...80 MHz |
| Current draw | 440mA @ 5.2V DC |
| DeviceNet communication rate | 125 Kbps (500 m max), 250 Kbps (250 m max), 500 Kbps (100 m max) |
| DeviceNet connector torque | 0.56 nm |
| DeviceNet current draw | 110mA @ 24V DC Class 2/SELV |
| DeviceNet current range | 11...25V DC |
| EFT/B immunity | ±2kV @ 5kHz on communications ports |
| Emissions | CISPR 11 (IEC 61000-6-4): Group 1, Class A |
| Enclosure type rating | None (open-style) |
| ESD immunity | 6 kV contact discharges, 8 kV air discharges |
| Height | 118 mm |
Show all 38 specificationsShow fewer specifications
| Isolation voltage | 30V (continuous), basic insulation type, DeviceNet to backplane, Type tested at 710V DC @ 60s |
|---|---|
| Module location | DIN rail or panel mount |
| Mounting screw torque | 1.16 Nm (10 in-lb) - use M4 or #8 screws |
| Nonoperating temperature | -40 to 85 °C |
| Number of HW-interfaces industrial Ethernet | 1 |
| Number of nodes, max | 64 nodes |
| Operating temperature | 0 to 60 °C |
| Ports | 1 DeviceNet open-style 5-pin linear plug |
| Power dissipation | 4.7 W |
| Power supply distance rating | 4 modules |
| Radiated RF immunity | 10 V/m with 1 kHz sine-wave 80% AM from 80...2000 MHz, 10 V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz, 1 V/m with 1 kHz sine-wave 80% AM from 2000...2700 MHz |
| Relative humidity | 5...95% noncondensing |
| Shock | Operating: 30 G |
| Slot width | 1 |
| Supporting protocol for DeviceNet | Yes |
| Surge transient immunity | ±2 kV line-earth (CM) on communication ports |
| Surrounding air temperature, max | 60 °C |
| Type of data transmission | Other |
| Vibration | 2 G @ 10...500 Hz |
| Weight, approx | 0.28 kg |
| Width | 50 mm |
| Wire category | 2 - on communication ports |
| Wire size | 802.3 compliant shielded or unshielded twisted pair |
Description
The Allen-Bradley 1769-SDN is a CompactLogix DeviceNet Scanner Module according to Rockwell Automation's product data. Rockwell lists a maximum of 64 nodes and DeviceNet communication rates of 125 Kbps (500 m max), 250 Kbps (250 m max) and 500 Kbps (100 m max). It has one DeviceNet open-style 5-pin linear plug, occupies one slot, and measures 50 mm wide, 118 mm high and 87 mm deep. Rockwell lists the lifecycle status as Discontinued and names 1788-EN2DNR as an Engineering Replacement.
Application: Communication module
Used with: CompactLogix and 1769 Compact I/O
What is the 1769-SDN used for?
As a DeviceNet scanner, it connects a CompactLogix system to the devices on a DeviceNet network. Rockwell gives its enclosure type rating as none (open-style), with DIN rail or panel mounting.
Key features
- Scans a DeviceNet network of up to 64 nodes
- Supports 125, 250 and 500 Kbps communication rates
- One open-style 5-pin linear DeviceNet plug
- Mounts on DIN rail or panel, one slot wide
- Rated for 0 to 60 °C surrounding air
Documents and Resources
OEM successor to 1769-SDN
1788-EN2DNR is named by Allen-Bradley as the successor. It is an upgrade, not a like-for-like spare: check wiring, I/O and configuration for your installation before ordering it. Contact sales@timcontrols.com if you need one.
Associated Products
| Image | Product | Description | Stock | View | Add to RFQ |
|---|---|---|---|---|---|
 | 1769-AENTRAllen-Bradley | 1769 EtherNet/IP adapter, 10/100 Mbps, two ports | In stock | View | |
 | 1768-ENBTAllen-Bradley | CompactLogix L4X EtherNet/IP Module | In stock | View |
Product Questions
Is the 1769-SDN discontinued?
Yes. Its manufacturer lifecycle status is Discontinued.
Is there a replacement for the 1769-SDN?
The 1788-EN2DNR is named by Allen-Bradley as the successor. It is an upgrade, not a like-for-like spare: check ratings, wiring and configuration before ordering it in its place.
