DEIF PPM-3

Technical specifications

Manufacturer

DEIF

Manufacturer part no.

PPM-3

Type

Protection & power management system

Application

Marine power management

Used with

Marine generator and switchboard systems

Product

PPM-3 protection and power management controller, DEIF Multi-line 2

Controls

Diesel generators, shaft generators, shore connections and bus tie breakers

Measuring voltage

100 to 690 V AC +/-20%

Measuring current

-/1 or -/5 A AC, from CTs

Measuring frequency

30 to 70 Hz

Current overload

4 x In continuously; 20 x In for 10 s (max. 75 A); 80 x In for 1 s (max. 300 A)

Auxiliary supply

12/24 V DC nominal (8 to 36 V DC operational), max. 11 W

Relay outputs

250 V AC / 30 V DC, 5 A

Communication options

Modbus RTU (RS-485), Profibus DP

Operating temperature

-25 to 70 °C (-25 to 60 °C with option N)

Storage temperature

-40 to 70 °C

Protection

Unit IP20; display IP40 (IP54 with gasket, option L)

EMC

EN 61000-6-2, EN 61000-6-4, IEC 60255-26, IEC 60533, IACS UR E10

Mounting

DIN rail or base mount with six screws

Weight

Base unit 1.6 kg; display 0.4 kg

Technical documents (1)

• DEIF PPM-3 data sheet 4921240337

Key features

• Built for marine power management
• Controls diesel generators, shaft generators, shore connections and bus ties
• Split busbars and ring bus connection
• Emergency generator control
• Automatic start and stop on power demand
• DEIF: being phased out, replaced by the iE 350 Marine

About the DEIF PPM-3

The DEIF PPM-3 is a protection and power management controller from DEIF's Multi-line 2 range, designed for marine applications. Each unit protects and controls one power source or breaker: a diesel generator, shaft generator, shore connection or bus tie breaker, and together they run the ship's power management, starting and stopping generators on power demand, with split busbars, ring bus connection and emergency generator control. DEIF states that the PPM-3 is being phased out and replaced by the iE 350 Marine.

What is the PPM-3 used for?

The PPM-3 sits in the main switchboard, one per generator or breaker. Because the power management system is configured across all the PPM-3 units on board, a failed unit is normally replaced with the same type and options so the rest of the system is unchanged.

Lifecycle and successor

Phased out.

OEM successor: iE 350 Marine

Before you order

What to photograph or confirm so the right unit is quoted.

Check the item number and variant on the label, the unit's role (generator, shaft generator, shore connection or bus tie) and the installed options, and note the software version. Send a label photo and the vessel name or IMO number.
