Mitsubishi Electric L02SCPU

Technical specifications

Manufacturer

Mitsubishi Electric

Manufacturer part no.

L02SCPU

Type

MELSEC-L CPU module

Application

PLC controller

Used with

MELSEC-L modules

Control method

Stored program cyclic operation

I/O control mode

Refresh mode; (The direct access input/output is available by specifying the direct access input/output (DX, DY).)

Programming language, Sequence control language

Relay symbol language, logic symbolic language, MELSAP3 (SFC), MELSAP-L, function block and structured text (ST)

Processing speed, Sequence instruction, LD X0

60 ns

Processing speed, Sequence instruction, MOV D0 D1

120 ns

Constant scan

0.5...2000 ms (setting is available in increments of 0.5 ms by parameter)

Program capacity

20K steps (80K bytes)

Memory capacity, Program memory (drive 0)

80K bytes

Memory capacity, Standard RAM (drive 3)

128K bytes

Memory capacity, Standard ROM (drive 4)

512K bytes

Number of I/O device points

8192 points (X/Y0...1FFF)

Number of I/O points

1024 points (X/Y0...3FF)

Clock function, Displayed information

Year, month, date, hour, minute, second, and day of week (automatic leap year detection)

Clock function, Accuracy

0 ˚C: -2.96...+3.74 s (TYP. +1.42 s)/day; 25 ˚C: -3.18...+3.74 s (TYP. +1.50 s)/day; 55 ˚C: -13.20...+2.12 s (TYP. -3.54 s)/day

Allowable momentary power failure time

The time differs depending on the power supply module used.

Internal current consumption (5 V DC)

Without display unit: 0.75 A; END cover (accessory): 0.04 A

External dimensions, Height

90 mm

External dimensions, Width

CPU: 70 mm; END cover (accessory): 13 mm

External dimensions, Depth

95 mm

Weight

CPU: 0.32 kg; END cover (accessory): 0.06 kg

High-speed input, 24V Input, Rated input voltage

24 V DC (+20/-15 %, ripple ratio within 5 %)

High-speed input, 24V Input, Rated input current

6.0 mA TYP. (at 24 V DC)

High-speed input, 24V Input, On voltage/on current

19 V or more/5 mA or more

High-speed input, 24V Input, Off voltage/off current

8 V or less/1.5 mA or less

High-speed input, 24V Input, Input resistance

3.8 kΩ

Technical documents (1)

• Mitsubishi Electric specification database, L02SCPU

Key features

• Program memory: 80K bytes
• Current consumption (5 V DC): Without display unit: 0.75 A
• Weight: CPU: 0.32 kg

About the Mitsubishi Electric L02SCPU

The Mitsubishi Electric L02SCPU is a MELSEC-L CPU module. Mitsubishi Electric's overview: Number of I/O points: 1024, number of I/O device points: 8192, program capacity: 20K steps, basic operation processing speed (LD X0): 60 ns, program memory capacity: 80K bytes, external interface: USB/RS-232, built-in I/O: sink output. Mitsubishi Electric lists it as discontinued since 2024/09, with repair support until 2031/09. Mitsubishi Electric names the R00CPU, R01CPU and R02CPU as replacement models.

What is the L02SCPU used for?

The L02SCPU runs the control program in a MELSEC-L system, with its modules joined side by side and no base unit, and its own built-in I/O.

Lifecycle and successor

Discontinued.

OEM successor: R00CPU

Before you order

What to photograph or confirm so the right unit is quoted.

Check the model name L02SCPU on the rating plate, with the serial number and function version. Send us a photo of the rating plate and we will confirm the details before quoting.
