Mitsubishi Electric L60AD4

Technical specifications

Manufacturer

Mitsubishi Electric

Manufacturer part no.

L60AD4

Type

Analog input module

Application

I/O module

Used with

MELSEC-L CPU modules

Number of analog input points

4 points (4 channels)

Analog input, Voltage

-10...+10 V DC (input resistance 1 MΩ)

Analog input, Current

0...20 mA DC (input resistance 250 Ω)

Digital output

-20480...+20479; (When the scaling function is used: -32768...32767)

I/O characteristics, resolution, Input range

Digital output value (resolution)

I/O characteristics, resolution, Voltage input, 0...10 V

0...20000 (500 µV)

I/O characteristics, resolution, Voltage input, 0...5 V

0...20000 (250 µV)

I/O characteristics, resolution, Voltage input, 1...5 V

0...20000 (200 µV)

I/O characteristics, resolution, Voltage input, 1...5 V (extended mode)

-5000...22500 (200 µV)

I/O characteristics, resolution, Voltage input, -10...10 V

-20000...20000 (500 µV)

I/O characteristics, resolution, Voltage input, User range setting

-20000...20000 (307 µV)

I/O characteristics, resolution, Current input, 0...20 mA

0...20000 (1000 nA)

I/O characteristics, resolution, Current input, 4...20 mA

0...20000 (800 nA)

I/O characteristics, resolution, Current input, 4...20 mA (extended mode)

-5000...22500 (800 nA)

I/O characteristics, resolution, Current input, User range setting

-20000...20000 (1230 nA)

Accuracy (accuracy relative to maximum value of the digital output value), Ambient temperature: 25±5 ﾟC

Within ±0.1 %

Accuracy (accuracy relative to maximum value of the digital output value), Ambient temperature: 0...55 ﾟC

Within ±0.2 %

A/D conversion speed

High-speed: 20 µs/channel; Medium speed: 80 µs/channel; Low speed: 1 ms/channel

Absolute maximum input, Voltage

±15 V

Absolute maximum input, Current

±30 mA

Isolation method

Between I/O terminals and programmable controller power supply: Photocoupler; Between analog input channels: Non-isolation

Dielectric withstand voltage

Between I/O terminals and programmable controller power supply: 500 V AC rms for 1 minute

Insulation resistance

Between I/O terminals and programmable controller power supply: 500 V DC 10 MΩ or higher

External interface

18-point terminal block (M3 screw)

Number of occupied I/O points

16 points (I/O assignment: Intelligent 16 points)

Technical documents (1)

• Mitsubishi Electric specification database, L60AD4

Key features

• Number of analog input points: 4 points (4 channels)
• Analog input, Voltage: -10...+10 V DC (input resistance 1 MΩ)
• Analog input, Current: 0...20 mA DC (input resistance 250 Ω)
• I/O characteristics, resolution, Input range: Digital output value (resolution)
• I/O characteristics, resolution, Voltage input, 0...10 V: 0...20000 (500 µV)

About the Mitsubishi Electric L60AD4

The Mitsubishi Electric L60AD4 is a MELSEC-L analogue input module. Mitsubishi Electric's overview: 4 channels, input: -10...10 V DC, 0...20 mA DC, output (resolution): 0...20000, -20000...20000, conversion speed: 20 μs/channel, 18-point terminal block. Mitsubishi Electric names the R60AD4 and FX5-4AD as replacement models.

What is the L60AD4 used for?

The L60AD4 joins a MELSEC-L system beside the CPU, with no base unit, and connects field signals to it.

Lifecycle and successor

Phased out.

OEM successor: R60AD4
