Mitsubishi Electric Q02HCPU

Technical specifications

Manufacturer

Mitsubishi Electric

Manufacturer part no.

Q02HCPU

Type

MELSEC-Q CPU module

Application

PLC controller

Used with

MELSEC-Q base units

Control method

Stored program cyclic operation

I/O control mode

Refresh mode; (The direct access input/output is available by specifying the direct access input/output (DX, DY).)

Programming language, Sequence control language

Relay symbol language, logic symbolic language, MELSAP3 (SFC), MELSAP-L, function block and structured text (ST)

Processing speed, Sequence instruction, LD X0

34 ns

Processing speed, Sequence instruction, MOV D0 D1

102 ns

Constant scan

0.5...2000 ms (setting is available in increments of 0.5 ms by parameter)

Program capacity

28K steps (112K bytes)

Memory capacity, Program memory (drive 0)

112K bytes

Memory capacity, Memory card (RAM) (drive 1)

Size of the installed memory card (2M bytes max.)

Memory capacity, Memory card (ROM) (drive 2)

Size of the installed memory card (Flash card: 4M bytes max., ATA card: 32M bytes max.)

Memory capacity, Standard RAM (drive 3)

128K bytes

Memory capacity, Standard ROM (drive 4)

112K bytes

Memory capacity, CPU shared memory, QCPU standard memory

8K bytes

Number of I/O device points

8192 points (X/Y0...1FFF)

Number of I/O points

4096 points (X/Y0...FFF)

RUN/PAUSE contact

One contact can be set up in X0 to X1FFF for each of RUN and PAUSE.

Clock function

Year, month, date, hour, minute, second, and day of week (automatic leap year detection); Accuracy: -3.18...+5.25 s (TYP. +2.12 s)/d at 0 ˚C; Accuracy: -3.93...+5.25 s (TYP. +1.90 s)/d at 25 ˚C; Accuracy: -14.69...+3.53 s (TYP. -3.67 s)/d at 55 ˚C

Allowable momentary power failure time

The time differs depending on the power supply module used.

Internal current consumption (5 V DC)

0.64 A

External dimensions, Height

98 mm

External dimensions, Width

27.4 mm

External dimensions, Depth

89.3 mm

Weight

0.20 kg

Operating ambient temperature

0...55 ˚C

Storage ambient temperature

-25...75 ˚C; (The storage ambient temperature is -20 to 75 ˚C if the system includes the AnS/A Series modules.)

Technical documents (1)

• Mitsubishi Electric specification database, Q02HCPU

Key features

• Program memory: 112K bytes
• Current consumption (5 V DC): 0.64 A
• Weight: 0.20 kg

About the Mitsubishi Electric Q02HCPU

The Mitsubishi Electric Q02HCPU is a MELSEC-Q CPU module. Mitsubishi Electric's overview: Number of I/O points: 4096, number of I/O device points: 8192, program capacity: 28K steps, basic operation processing speed (LD X0): 34 ns, program memory capacity: 112K bytes, external interface: USB/RS-232, with memory card interface. Mitsubishi Electric lists it as discontinued since 2018/09. Mitsubishi Electric names the R02CPU and R04CPU as replacement models.

What is the Q02HCPU used for?

The Q02HCPU runs the control program on a MELSEC-Q base unit, working with the I/O, intelligent function and network modules on the base.

Lifecycle and successor

Discontinued.

OEM successor: R02CPU
