Mitsubishi Electric Q00JCPU

Technical specifications

Manufacturer

Mitsubishi Electric

Manufacturer part no.

Q00JCPU

Type

MELSEC-Q CPU module

Application

PLC controller

Used with

MELSEC-Q base units

Control method

Stored program cyclic operation

I/O control mode

Refresh mode; (The direct access input/output is available by specifying the direct access input/output (DX, DY).)

Programming language, Sequence control language

Relay symbol language, logic symbolic language, MELSAP3 (SFC), MELSAP-L, function block and structured text (ST)

Processing speed, Sequence instruction, LD X0

200 ns

Processing speed, Sequence instruction, MOV D0 D1

700 ns

Constant scan

1...2000 ms (setting is available in increments of 1 ms by parameter)

Program capacity

8K steps (32K bytes)

Memory capacity, Program memory (drive 0)

58K bytes

Memory capacity, Standard ROM (drive 4)

58K bytes

Number of I/O device points

2048 points (X/Y0...7FF)

Number of I/O points

256 points (X/Y0...FF)

RUN/PAUSE contact

One contact can be set up in X0 to X7FF for each of RUN and PAUSE.

Clock function

Year, month, date, hour, minute, second, and day of week (automatic leap year detection); Accuracy: -3.20...+5.27 s (TYP. +1.98 s)/d at 0 ˚C; Accuracy: -2.57...+5.27 s (TYP. +2.22 s)/d at 25 ˚C; Accuracy: -11.68...+3.65 s (TYP. -2.64 s)/d at 55 ˚C

Allowable momentary power failure time

Within 20 ms (100 V AC or more)

Internal current consumption (5 V DC)

0.26 A

External dimensions, Height

98 mm

External dimensions, Width

244.4 mm

External dimensions, Depth

98 mm

Weight

0.66 kg

Input power supply voltage

100...240 V AC (-15 %...+10 %)

Input frequency

50/60 Hz ±5 %

Input voltage distortion

Within 5 %

Maximum input apparent power

105 VA

Inrush current

40 A, within 8 ms

Rated output current, 5 V DC

3 A

Technical documents (1)

• Mitsubishi Electric specification database, Q00JCPU

Key features

• Program memory: 58K bytes
• Constant scan: 1...2000 ms (setting is available in increments of 1 ms by parameter)
• Current consumption (5 V DC): 0.26 A
• Weight: 0.66 kg

About the Mitsubishi Electric Q00JCPU

The Mitsubishi Electric Q00JCPU is a MELSEC-Q CPU module. Mitsubishi Electric's overview: Number of I/O points: 256, number of I/O device points: 2048, program capacity: 8K steps, basic operation processing speed (LD X0): 200 ns, program memory capacity: 58K bytes, external interface: RS-232, without memory card interface, base: 5 slots, power-supply: 100...240 V AC input/5 V DC 3A output. Mitsubishi Electric lists it as discontinued since 2018/09. Mitsubishi Electric names the R00CPU as its replacement model.

What is the Q00JCPU used for?

The Q00JCPU runs the control program on a MELSEC-Q base unit, working with the I/O, intelligent function and network modules on the base.

Lifecycle and successor

Discontinued.

OEM successor: R00CPU

Before you order

What to photograph or confirm so the right unit is quoted.

Check the model name Q00JCPU on the rating plate, with the serial number and function version. Send us a photo of the rating plate and we will confirm the details before quoting.
