Mitsubishi Electric R08CPU

MELSEC iQ-R CPU Module, 80K Steps Program, 4096 I/O

Read from the product label

Maker: Mitsubishi Electric
Part no.: R08CPU
Serial / rev.: as printed on your unit

Image is for illustrative purposes only. Please refer to product description.

Delivery options

Mitsubishi Electric R08CPU is a MELSEC iQ-R CPU module with 80K steps of program, 4096 I/O points and USB and Ethernet ports.

Manufacturer: Mitsubishi Electric
Manufacturer part no.: R08CPU
Product family: Mitsubishi MELSEC iQ-R CPU Modules
Type: MELSEC iQ-R CPU module
Category: PLCs & processors › CPU and processor modules
Lifecycle: Active
OEM successor: Not stated
Technical datasheet: Data sheet

Technical specifications

Manufacturer: Mitsubishi Electric
Manufacturer part no.: R08CPU
Type: MELSEC iQ-R CPU module
Application: PLC controller
Used with: MELSEC iQ-R base units
Operation control method: Stored program cyclic operation
I/O control mode: Refresh mode; (The direct access input/output is available by specifying the direct access input/output (DX, DY).)
Instruction processing time, LD instruction: 0.98 ns
Instruction processing time, MOV instruction: 1.96 ns
Instruction processing time (structured text), IF: 1.96 ns
Instruction processing time (structured text), CASE: 1.96 ns
Instruction processing time (structured text), FOR: 1.96 ns
Memory capacity, Program capacity: 80K steps (320K bytes)
Memory capacity, Program memory: 320K bytes
Memory capacity, SD memory card: Differs depending on the SD memory card used. ; (SD/SDHC memory card: 32G bytes maximum)
Memory capacity, Device/label memory: 1188K bytes
Memory capacity, Signal flow memory, Area for programs: 10K bytes
Memory capacity, Signal flow memory, Area for function blocks: 256K bytes
Memory capacity, Data memory: 5M bytes
Memory capacity, Function memory: 5120K bytes
Memory capacity, CPU buffer memory: 1072K bytes (536K words); (including the fixed scan communication area (24K words))
Memory capacity, Refresh memory: 2048K bytes
Number of storable folders, Data memory: 512
Number of storable folders, Function memory: 512
Number of storable folders, SD memory card: • NZ1MEM-2GBSD: 256; • NZ1MEM-4GBSD, NZ1MEM-8GBSD, NZ1MEM-16GBSD: 32767
USB port: USB2.0 High Speed (miniB)×1
Ethernet port: 10BASE-T/100BASE-TX×1
Clock function: Year, month, date, hour, minute, second, and day of week (automatic leap year adjustment); Accuracy: -1.00...+1.00 s/d at 0...55 ˚C
Backup power, Backup method: Capacitor
Backup power, Backup power time: Three minutes

Show all 116 specifications

Backup power, Data retained: Device/label memory, clock data
Allowable momentary power failure time: The time differs depending on the power supply module used.
Internal current consumption (5 V DC): 0.67 A
External dimensions, Height: 106 mm (base unit mounting side: 98 mm)
External dimensions, Width: 27.8 mm
External dimensions, Depth: 110 mm
Weight: 0.20 kg
Programming language: Ladder diagram (LD), sequential function chart (SFC), structured text (ST), function block diagram (FBD/LD)
Programming supporting function: Function block (FB), label programming (system/local/global)
Program operation, Execution type, Standard program: Initial execution type, scan execution type, fixed scan execution type, event execution type, standby type
Program operation, Type of interrupt, Standard program: Internal timer interrupt (I28 to I31), high-speed internal timer interrupt 1 (I49), high-speed internal timer interrupt 2 (I48), interrupt by modules, inter-module synchronous interrupt (I44), multiple CPU synchronous interrupt (I45)
Number of executable programs, General program: 252
Number of FB files, FB file: 128
Tact performance, Constant scan: 0.2...2000 ms (in 0.1 ms increments)
Tact performance, Cyclic interrupt, Interrupt using the internal timer (I28...I31): 0.5...1000 ms (in 0.5 ms increments)
Tact performance, Cyclic interrupt, High-speed internal timer interrupt 1 (I49): 0.05...1000 ms (in 0.05 ms increments)
Tact performance, Cyclic interrupt, High-speed internal timer interrupt 2 (I48): 0.05...1000 ms (in 0.05 ms increments)
Tact performance, Cyclic interrupt, Inter-module synchronous interrupt (I44): 0.1...10.00 ms (in 0.05 ms increments)
Tact performance, Cyclic interrupt, Multiple CPU synchronous interrupt (I45): 0.1...10.00 ms (in 0.05 ms increments)
Timer performance, Low-speed timer: 1...1000 ms (Default: 100 ms)
Timer performance, High-speed timer: 0.01...100 ms (Default: 10 ms)
Timer performance, Long timer: 0.001...1000 ms (Default: 0.001 ms)
Number of I/O points: 4096 points
Number of user device points, Input (X): 12288 points (fixed)
Number of user device points, Output (Y): 12288 points (fixed)
Number of user device points, Internal relay (M): 12288 points (user-changeable)
Number of user device points, Latch relay (L): 8192 points (user-changeable)
Number of user device points, Link relay (B): 8192 points (user-changeable)
Number of user device points, Link special relay (SB): 2048 points (user-changeable)
Number of user device points, Annunciator (F): 2048 points (user-changeable)
Number of user device points, Edge relay (V): 2048 points (user-changeable)
Number of user device points, Step relay (S): 0 points (user-changeable)
Number of user device points, Timer device, Timer (T): 1024 points (user-changeable)
Number of user device points, Timer device, Long timer (LT): 1024 points (user-changeable)
Number of user device points, Retentive timer device, Retentive timer (ST): 0 points (user-changeable)
Number of user device points, Retentive timer device, Long retentive timer (LST): 0 points (user-changeable)
Number of user device points, Counter device, Counter (C): 512 points (user-changeable)
Number of user device points, Counter device, Long counter (LC): 512 points (user-changeable)
Number of user device points, Data register (D): 18432 points (user-changeable)
Number of user device points, Link register (W): 8192 points (user-changeable)
Number of user device points, Link special register (SW): 2048 points (user-changeable)
Number of system device points, Special relay (SM): 4096 points (fixed)
Number of system device points, Special register (SD): 4096 points (fixed)
Number of system device points, Function input (FX): 16 points (fixed)
Number of system device points, Function output (FY): 16 points (fixed)
Number of system device points, Function register (FD): 5 points × 4 words (fixed)
Number of file register points, File register (R/ZR): 0 points (user-changeable)
Number of index register points, Index register (Z): 20 points (user-changeable, up to 24 points)
Number of index register points, Long index register (LZ): 2 points (user-changeable, up to 12 points)
Number of pointer points, Pointer (P) (global/local): 8192 points (user-changeable, up to 16384 points)
Number of pointer points, Interrupt pointer (I): 1024 points (fixed)
Number of link direct device points, Link input (J☐\X☐): 160K points maximum
Number of link direct device points, Link output (J☐\Y☐): 160K points maximum
Number of link direct device points, Link relay (J☐\B☐): 640K points maximum
Number of link direct device points, Link register (J☐\W☐): 2560K points maximum
Number of link direct device points, Link special relay (J☐\SB☐): 5120 points maximum
Number of link direct device points, Link special register (J☐\SW☐): 5120 points maximum
Number of module access device points, Intelligent function module device (U☐\G☐): 268435456 points maximum
Number of CPU buffer memory access device points, Buffer memory (U3E☐\G☐): 268435456 points maximum
Number of CPU buffer memory access device points, Fixed scan communication area in the buffer memory (U3E☐\HG☐): 12288 points maximum
Number of refresh data register points, Refresh data register (RD): 524288 points (1048576 points maximum)
Number of nesting points, Nesting (N): 15 points
Number of other device points, SFC block device (BL): 320 points
Number of other device points, SFC transition device (TR): 0 points (Can be used for device comments only)
Transmission specifications, Data transmission speed: 100/10 Mbps
Transmission specifications, Communication mode: 100BASE-TX: Full-duplex/half-duplex; 10BASE-T: Full-duplex/half-duplex
Transmission specifications, Interface: RJ45 (AUTO MDI/MDI-X)
Transmission specifications, Transmission method: Base band
Transmission specifications, Maximum frame size: 1518 bytes
Transmission specifications, Jumbo frame: Not available
Transmission specifications, Maximum segment length: 100 m (length between hub and node)
Transmission specifications, IP version: IPv4
Sending/receiving data storage memory, Number of simultaneously open connections: 16 connections (connections usable on a program)
Sending/receiving data storage memory, Socket communications: 5K words × 16
Operating ambient temperature: 0...55 ˚C (When an extended temperature range base unit is not used); 0...60 ˚C (When an extended temperature range base unit is used)
Storage ambient temperature: -25...75 ˚C
Operating ambient humidity: 5...95 %RH, non-condensing
Storage ambient humidity: 5...95 %RH, non-condensing
Vibration resistance, IEC 61131-2: 2007/JIS B 3502: 2011, Under intermittent vibration: Frequency: 5...8.4 Hz, Half amplitude: 3.5 mm; Frequency: 8.4...150 Hz, Constant acceleration: 9.8 m/s 2 ; Sweep count: 10 times each in X, Y, and Z directions
Vibration resistance, IEC 61131-2: 2007/JIS B 3502: 2011, Under continuous vibration: Frequency: 5...8.4 Hz, Half amplitude: 1.75 mm; Frequency: 8.4...150 Hz, Constant acceleration: 4.9 m/s 2
Shock resistance, IEC 61131-2: 2007/JIS B 3502: 2011: Three shocks in each direction per axis, on 3 mutually perpendicular axes (total of 18 shocks)
Operating atmosphere: No corrosive gases, flammable gases, less conductive dust
Operating altitude: 0...2000 m
Installation location: Inside a control panel
Overvoltage category: II or less
Pollution degree: 2 or less
