Image is for illustrative purposes only. Please refer to product description.
- Manufacturer
- Mitsubishi Electric
- Manufacturer part number
- R16CPU
- Product family
- Mitsubishi MELSEC iQ-R CPU Modules
- Category
- PLCs and I/O › CPU and processor modules
- Technical datasheet
- Data sheet
Specifications
| Attribute | Value |
|---|---|
| Type | MELSEC iQ-R CPU module |
| Manufacturer lifecycle | Active |
| Operation control method | Stored program cyclic operation |
| I/O control mode | Refresh mode; (The direct access input/output is available by specifying the direct access input/output (DX, DY).) |
| Instruction processing time, LD instruction | 0.98 ns |
| Instruction processing time, MOV instruction | 1.96 ns |
| Instruction processing time (structured text), IF | 1.96 ns |
| Instruction processing time (structured text), CASE | 1.96 ns |
| Instruction processing time (structured text), FOR | 1.96 ns |
| Memory capacity, Program capacity | 160K steps (640K bytes) |
| Memory capacity, Program memory | 640K bytes |
| Memory capacity, SD memory card | Differs depending on the SD memory card used. ; (SD/SDHC memory card: 32G bytes maximum) |
| Memory capacity, Device/label memory | 1720K bytes |
| Memory capacity, Signal flow memory, Area for programs | 20K bytes |
| Memory capacity, Signal flow memory, Area for function blocks | 256K bytes |
Show all 113 specificationsShow fewer specifications
| Memory capacity, Data memory | 10M bytes |
|---|---|
| Memory capacity, Function memory | 5120K bytes |
| Memory capacity, CPU buffer memory | 1072K bytes (536K words); (including the fixed scan communication area (24K words)) |
| Memory capacity, Refresh memory | 2048K bytes |
| Number of storable folders, Data memory | 512 |
| Number of storable folders, Function memory | 512 |
| Number of storable folders, SD memory card | • NZ1MEM-2GBSD: 256; • NZ1MEM-4GBSD, NZ1MEM-8GBSD, NZ1MEM-16GBSD: 32767 |
| USB port | USB2.0 High Speed (miniB)×1 |
| Ethernet port | 10BASE-T/100BASE-TX×1 |
| Clock function | Year, month, date, hour, minute, second, and day of week (automatic leap year adjustment); Accuracy: -1.00...+1.00 s/d at 0...55 ˚C |
| Backup power, Backup method | Capacitor |
| Backup power, Backup power time | Three minutes |
| Backup power, Data retained | Device/label memory, clock data |
| Allowable momentary power failure time | The time differs depending on the power supply module used. |
| Internal current consumption (5 V DC) | 0.67 A |
| External dimensions, Height | 106 mm (base unit mounting side: 98 mm) |
| External dimensions, Width | 27.8 mm |
| External dimensions, Depth | 110 mm |
| Weight | 0.20 kg |
| Programming language | Ladder diagram (LD), sequential function chart (SFC), structured text (ST), function block diagram (FBD/LD) |
| Programming supporting function | Function block (FB), label programming (system/local/global) |
| Program operation, Execution type, Standard program | Initial execution type, scan execution type, fixed scan execution type, event execution type, standby type |
| Program operation, Type of interrupt, Standard program | Internal timer interrupt (I28 to I31), high-speed internal timer interrupt 1 (I49), high-speed internal timer interrupt 2 (I48), interrupt by modules, inter-module synchronous interrupt (I44), multiple CPU synchronous interrupt (I45) |
| Number of executable programs, General program | 252 |
| Number of FB files, FB file | 128 |
| Tact performance, Constant scan | 0.2...2000 ms (in 0.1 ms increments) |
| Tact performance, Cyclic interrupt, Interrupt using the internal timer (I28...I31) | 0.5...1000 ms (in 0.5 ms increments) |
| Tact performance, Cyclic interrupt, High-speed internal timer interrupt 1 (I49) | 0.05...1000 ms (in 0.05 ms increments) |
| Tact performance, Cyclic interrupt, High-speed internal timer interrupt 2 (I48) | 0.05...1000 ms (in 0.05 ms increments) |
| Tact performance, Cyclic interrupt, Inter-module synchronous interrupt (I44) | 0.1...10.00 ms (in 0.05 ms increments) |
| Tact performance, Cyclic interrupt, Multiple CPU synchronous interrupt (I45) | 0.1...10.00 ms (in 0.05 ms increments) |
| Timer performance, Low-speed timer | 1...1000 ms (Default: 100 ms) |
| Timer performance, High-speed timer | 0.01...100 ms (Default: 10 ms) |
| Timer performance, Long timer | 0.001...1000 ms (Default: 0.001 ms) |
| Number of I/O points | 4096 points |
| Number of user device points, Input (X) | 12288 points (fixed) |
| Number of user device points, Output (Y) | 12288 points (fixed) |
| Number of user device points, Internal relay (M) | 12288 points (user-changeable) |
| Number of user device points, Latch relay (L) | 8192 points (user-changeable) |
| Number of user device points, Link relay (B) | 8192 points (user-changeable) |
| Number of user device points, Link special relay (SB) | 2048 points (user-changeable) |
| Number of user device points, Annunciator (F) | 2048 points (user-changeable) |
| Number of user device points, Edge relay (V) | 2048 points (user-changeable) |
| Number of user device points, Step relay (S) | 0 points (user-changeable) |
| Number of user device points, Timer device, Timer (T) | 1024 points (user-changeable) |
| Number of user device points, Timer device, Long timer (LT) | 1024 points (user-changeable) |
| Number of user device points, Retentive timer device, Retentive timer (ST) | 0 points (user-changeable) |
| Number of user device points, Retentive timer device, Long retentive timer (LST) | 0 points (user-changeable) |
| Number of user device points, Counter device, Counter (C) | 512 points (user-changeable) |
| Number of user device points, Counter device, Long counter (LC) | 512 points (user-changeable) |
| Number of user device points, Data register (D) | 18432 points (user-changeable) |
| Number of user device points, Link register (W) | 8192 points (user-changeable) |
| Number of user device points, Link special register (SW) | 2048 points (user-changeable) |
| Number of system device points, Special relay (SM) | 4096 points (fixed) |
| Number of system device points, Special register (SD) | 4096 points (fixed) |
| Number of system device points, Function input (FX) | 16 points (fixed) |
| Number of system device points, Function output (FY) | 16 points (fixed) |
| Number of system device points, Function register (FD) | 5 points × 4 words (fixed) |
| Number of file register points, File register (R/ZR) | 0 points (user-changeable) |
| Number of index register points, Index register (Z) | 20 points (user-changeable, up to 24 points) |
| Number of index register points, Long index register (LZ) | 2 points (user-changeable, up to 12 points) |
| Number of pointer points, Pointer (P) (global/local) | 8192 points (user-changeable, up to 16384 points) |
| Number of pointer points, Interrupt pointer (I) | 1024 points (fixed) |
| Number of link direct device points, Link input (J☐\X☐) | 160K points maximum |
| Number of link direct device points, Link output (J☐\Y☐) | 160K points maximum |
| Number of link direct device points, Link relay (J☐\B☐) | 640K points maximum |
| Number of link direct device points, Link register (J☐\W☐) | 2560K points maximum |
| Number of link direct device points, Link special relay (J☐\SB☐) | 5120 points maximum |
| Number of link direct device points, Link special register (J☐\SW☐) | 5120 points maximum |
| Number of module access device points, Intelligent function module device (U☐\G☐) | 268435456 points maximum |
| Number of CPU buffer memory access device points, Buffer memory (U3E☐\G☐) | 268435456 points maximum |
| Number of CPU buffer memory access device points, Fixed scan communication area in the buffer memory (U3E☐\HG☐) | 12288 points maximum |
| Number of refresh data register points, Refresh data register (RD) | 524288 points (1048576 points maximum) |
| Number of nesting points, Nesting (N) | 15 points |
| Number of other device points, SFC block device (BL) | 320 points |
| Number of other device points, SFC transition device (TR) | 0 points (Can be used for device comments only) |
| Transmission specifications, Data transmission speed | 100/10 Mbps |
| Transmission specifications, Communication mode | 100BASE-TX: Full-duplex/half-duplex; 10BASE-T: Full-duplex/half-duplex |
| Transmission specifications, Interface | RJ45 (AUTO MDI/MDI-X) |
| Transmission specifications, Transmission method | Base band |
| Transmission specifications, Maximum frame size | 1518 bytes |
| Transmission specifications, Jumbo frame | Not available |
| Transmission specifications, Maximum segment length | 100 m (length between hub and node) |
| Transmission specifications, IP version | IPv4 |
| Sending/receiving data storage memory, Number of simultaneously open connections | 16 connections (connections usable on a program) |
| Sending/receiving data storage memory, Socket communications | 5K words × 16 |
| Operating ambient temperature | 0...55 ˚C (When an extended temperature range base unit is not used); 0...60 ˚C (When an extended temperature range base unit is used) |
| Storage ambient temperature | -25...75 ˚C |
| Operating ambient humidity | 5...95 %RH, non-condensing |
| Storage ambient humidity | 5...95 %RH, non-condensing |
| Vibration resistance, IEC 61131-2: 2007/JIS B 3502: 2011, Under intermittent vibration | Frequency: 5...8.4 Hz, Half amplitude: 3.5 mm; Frequency: 8.4...150 Hz, Constant acceleration: 9.8 m/s 2 ; Sweep count: 10 times each in X, Y, and Z directions |
| Vibration resistance, IEC 61131-2: 2007/JIS B 3502: 2011, Under continuous vibration | Frequency: 5...8.4 Hz, Half amplitude: 1.75 mm; Frequency: 8.4...150 Hz, Constant acceleration: 4.9 m/s 2 |
| Shock resistance, IEC 61131-2: 2007/JIS B 3502: 2011 | Three shocks in each direction per axis, on 3 mutually perpendicular axes (total of 18 shocks) |
| Operating atmosphere | No corrosive gases, flammable gases, less conductive dust |
| Operating altitude | 0...2000 m |
| Installation location | Inside a control panel |
| Overvoltage category | II or less |
| Pollution degree | 2 or less |
Description
The Mitsubishi Electric R16CPU is a MELSEC iQ-R CPU module. Mitsubishi Electric's overview: Number of I/O points: 4096, program capacity: 160K steps, basic operation processing speed (LD X0): 0.98 ns, program memory capacity: 640K bytes, external interface: USB/Ethernet. Mitsubishi Electric lists it as on sale.
Application: PLC controller
Used with: MELSEC iQ-R base units
What is the R16CPU used for?
The R16CPU runs the control program on a MELSEC iQ-R base unit, working with the I/O, intelligent function and network modules on the base.
Key features
- Ethernet: 100/10 Mbps
- Current consumption (5 V DC): 0.67 A
- Weight: 0.20 kg
Documents and Resources
Associated Products
| Image | Product | Description | Stock | View | Add to RFQ |
|---|---|---|---|---|---|
![]() | R01CPUMitsubishi Electric | MELSEC iQ-R CPU Module, 15K Steps Program, 4096 I/O | In stock | View | |
![]() | R02CPUMitsubishi Electric | MELSEC iQ-R CPU Module, 20K Steps Program, 4096 I/O | In stock | View | |
![]() | R120CPUMitsubishi Electric | MELSEC iQ-R CPU Module, 1200K Steps Program, 4096 I/O | In stock | View | |
![]() | R120ENCPUMitsubishi Electric | MELSEC iQ-R CPU Module, 1200K Steps Program, 4096 I/O | In stock | View | |
![]() | R120PCPUMitsubishi Electric | MELSEC iQ-R CPU Module, 1200K Steps Program, 4096 I/O | In stock | View | |
![]() | R04CPUMitsubishi Electric | MELSEC iQ-R CPU Module, 40K Steps Program, 4096 I/O | In stock | View | |
![]() | R08CPUMitsubishi Electric | MELSEC iQ-R CPU Module, 80K Steps Program, 4096 I/O | In stock | View | |
![]() | R32CPUMitsubishi Electric | MELSEC iQ-R CPU Module, 320K Steps Program, 4096 I/O | In stock | View | |
![]() | R04ENCPUMitsubishi Electric | MELSEC iQ-R CPU Module, 40K Steps Program, 4096 I/O | In stock | View | |
![]() | R08ENCPUMitsubishi Electric | MELSEC iQ-R CPU Module, 80K Steps Program, 4096 I/O | In stock | View | |
![]() | R16ENCPUMitsubishi Electric | MELSEC iQ-R CPU Module, 160K Steps Program, 4096 I/O | In stock | View | |
![]() | R16PCPUMitsubishi Electric | MELSEC iQ-R CPU Module, 160K Steps Program, 4096 I/O | In stock | View |
Product Questions
Is the R16CPU discontinued?
No. Its manufacturer lifecycle status is Active.
Can another Mitsubishi Electric MELSEC iQ-R CPU Modules part replace it?
Potential replacements must be checked against the required ratings, dimensions and connections. Sharing a family name does not establish interchangeability.
Do you ship worldwide?
Yes. TimControls ships worldwide. Parts usually ship within 3 to 7 working days of order confirmation, and the exact lead time and shipping options are stated on your quote. Include your delivery country and postal code when you ask for a quote.
