Omron CJ1W-INT01

Technical specifications

Manufacturer

Omron

Manufacturer part no.

CJ1W-INT01

Type

Digital input module

Application

I/O module

Used with

CJ-series CPUs (CJ1, CJ2)

I/O system

CJ I/O Bus

Expansion unit type

Basic I/O Unit

Type of module

Digital I/O

Number of digital inputs

16

Digital input type

Interrupt, PNP/NPN

Permitted voltage at input

20.4-26.4 V

OFF/ON delay

0.05-.5 ms

I/O connection type

Screw

Number of I/O connectors

1

Number of COM terminals

2

Height

90 mm

Width

31 mm

Depth

89 mm

Weight

60 g

Technical documents (1)

• Omron product page CJ1W-INT01

Key features

• OFF/ON delay: 0.05-.5 ms
• Number of I/O connectors: 1
• Expansion unit type: Basic I/O Unit
• Size 90 mm high, 31 mm wide, 89 mm deep

About the Omron CJ1W-INT01

The Omron CJ1W-INT01 is a CJ1W digital input unit. Omron describes it as: Digital interrupt input unit, 16 x 24 VDC inputs, 2 max per CPU, screw terminal. Its specification table gives 16 digital inputs, interrupt, PNP/NPN inputs and 20.4-26.4 V input voltage. Omron's European product page carries no end-of-production notice for it.

What is the CJ1W-INT01 used for?

The CJ1W-INT01 mounts on the CJ I/O bus beside a CJ-series CPU, which reads and writes its digital input signals each cycle.

Lifecycle and successor

Active.

Before you order

What to photograph or confirm so the right unit is quoted.

Check the model number CJ1W-INT01 on the unit's label, with its lot number. Send us a photo of the label and we will confirm the details before quoting.
