Omron NX-HB3201

Technical specifications

Manufacturer

Omron

Manufacturer part no.

NX-HB3201

Type

Temperature control module

Application

I/O module

Used with

NX-series controllers and NX bus couplers

I/O system

NX I/O Bus

Type of module

Temperature control

Permitted voltage at input

12-24 V

OFF/ON delay

10-10 ms

Number of digital outputs

4

Digital output type

PNP

Number of analog inputs

4

Linear analog input type

Current transformer

Resolution of the analog inputs

10 Bit

Input circuit type

Standard

Conversion time

10 ms/unit

Signal processing

Free running

I/O connection type

Push-in

Number of I/O connectors

1

Degree of protection (IP)

IP20

Height

100 mm

Width

12 mm

Depth

80 mm

Weight

70 g

Technical documents (1)

• Omron product page NX-HB3201

Key features

• Signal processing: Free running
• OFF/ON delay: 10-10 ms
• Degree of protection (IP): IP20
• Number of I/O connectors: 1
• Size 100 mm high, 12 mm wide, 80 mm deep

About the Omron NX-HB3201

The Omron NX-HB3201 is an NX temperature control unit. Omron describes it as: Heater Burnout Detection Unit, 4 CT inputs, 4 PNP Outputs, screwless push-in connector, 12 mm wide. Its specification table gives 4 digital outputs, 4 analogue inputs and 10 Bit input resolution. Omron's European product page carries no end-of-production notice for it.

What is the NX-HB3201 used for?

The NX-HB3201 slots onto the NX I/O bus next to an NX controller or bus coupler, carrying its temperature control signals to and from the machine.

Lifecycle and successor

Active.

Before you order

What to photograph or confirm so the right unit is quoted.

Check the model number NX-HB3201 on the unit's label, with its lot number. Send us a photo of the label and we will confirm the details before quoting.
