ABB 3BSC690074R1 DO890
DO890 digital output module
Image is for illustrative purposes only. Please refer to product description.
Delivery options
DO890 (3BSC690074R1) is an ABB S800 digital output module with 4 channels. Signal specification: 11 V, 40 mA.
- Manufacturer
- ABB
- Manufacturer part no.
- 3BSC690074R1
- Model
- DO890
- Product family
- S800 I/O Modules
- Type
- Digital output module
- Category
- PLCs and I/O › Digital I/O modules
- Lifecycle
- To be confirmed
- OEM successor
- Not stated
- Technical datasheet
- Data sheet
Technical specifications
- Manufacturer
- ABB
- Manufacturer part no.
- 3BSC690074R1
- Type
- Digital output module
- Application
- Switches discrete field outputs according to controller commands.
- Used with
- TU890, TU891
- Module model
- DO890
- Article number
- 3BSC690074R1
- Type
- Digital Output
- Number of channels
- 4
- Signal specification
- 11 V, 40 mA
- Signal type
- Solenoid driver
- HART
- No
- SOE
- No
- Redundancy
- No
- High integrity
- No
- Intrinsic safety
- Yes
- Isolation
- Individually isolated, channel-to-channel and to circuit common ground
- Output load
- 100 - 5000 Ω
- Current limiting
- Short circuit proof current limited output
- Power dissipation
- 4.4 W
- Current consumption +5 V Modulebus
- Typ. 80 mA, Max. <150 mA
- Current consumption +24 V external
- Typ. 250 mA, Max. <360 mA
- Temperature, Operating
- 0 to +55 °C (+32 to +131 °F)
- Temperature, Storage
- -40 to +70 °C (-40 to +158 °F)
- Relative humidity
- 5 to 95 %, non-condensing
- Protection class
- IP20 according to IEC 60529
- Use with MTU
- TU890, TU891
- Keying code
- AB
- Width
- 45 mm
- Height
- 119 mm
Show all 32 specificationsShow fewer
- Depth
- 102 mm, 111 mm including connector
- Weight
- 0.2 kg
Technical documents (1)
Key features
- 4 digital output channels
- Signal range: 11 V, 40 mA
- Isolation: Individually isolated, channel-to-channel and to circuit common ground
- Redundancy: No
- HART: No
About the ABB 3BSC690074R1
DO890 (3BSC690074R1) is an ABB S800 digital output module with 4 channels. Signal specification: 11 V, 40 mA. The module uses the S800 mechanical format. ABB lists individually isolated, channel-to-channel and to circuit common ground isolation. Order number 3BSC690074R1 identifies this module variant; the model name and revision should be checked together before replacement.
What is the 3BSC690074R1 used for?
Switches discrete field outputs according to controller commands.
Lifecycle and successor
To be confirmed.
Before you order
What to photograph or confirm so the right unit is quoted.
Confirm both DO890 and order number 3BSC690074R1, hardware revision, installed controller and I/O configuration. Match signal range, channel wiring, termination unit and keying. Confirm redundancy or safety requirements against the OEM system documentation; related modules are not automatically interchangeable.
Other parts in the ABB S800 I/O family
Listed for reference. They differ from the 3BSC690074R1 in rating, supply, interface or function and are not interchangeable with it unless ABB says so. Match the part number on your unit.
| Product | Type | Lifecycle | Qty Available | Price | Action |
|---|---|---|---|---|---|
| ABB 3BSC690071R1 AI890AI890 analog input module | Analog input module | To be confirmed | On Request | On request | View |
| ABB 3BSC690072R1 AO890AO890 analog output module | Analog output module | To be confirmed | On Request | On request | View |
| ABB 3BSC690073R1 DI890DI890 digital input module | Digital input module | To be confirmed | On Request | On request | View |
| ABB 3BSE008510R1 DO810DO810 digital output module | Digital output module | To be confirmed | On Request | On request | View |
| ABB 3BUR001455R1 DO814DO814 digital output module | Digital output module | To be confirmed | On Request | On request | View |
| ABB 3BSE013258R1 DO815DO815 digital output module | Digital output module | To be confirmed | On Request | On request | View |
| ABB 3BSE069053R1 DO818DO818 digital output module | Digital output module | To be confirmed | On Request | On request | View |
| ABB 3BSE008514R1 DO820DO820 digital output module | Digital output module | To be confirmed | On Request | On request | View |
| ABB 3BSE013250R1 DO821DO821 digital output module | Digital output module | To be confirmed | On Request | On request | View |
| ABB 3BSE069055R1 DO828DO828 digital output module | Digital output module | To be confirmed | On Request | On request | View |
| ABB 3BSE020838R1 DO840DO840 digital output module | Digital output module | To be confirmed | On Request | On request | View |
| ABB 3BSE028602R1 DO880DO880 digital output module | Digital output module | To be confirmed | On Request | On request | View |
