Allen-Bradley 1763-L16BBB

Technical specifications

Manufacturer

Allen-Bradley

Manufacturer part no.

1763-L16BBB

Type

MicroLogix controller

Application

PLC controller

Used with

MicroLogix system

Dimensions, HxWxD

90 x 110 x 87 mm 3.5 x 4.33 x 3.43 in., Height is 104 mm (4.09 in.) with DIN latch open

Shipping weight

0.9 kg (2.0 lbs)

Number of I/O

12 inputs (10 digital and 2 analog) and 6 outputs

Power supply voltage

24V DC (-15%, +10%), Class 2 SELV

Power supply inrush current, max

24V DC: 15 A for 20 ms

Maximum power consumption

35 W, See Figure 82

Input circuit type

Digital: 24V DC sinking/sourcing (standard and high-speed), Analog: 0…10V DC

Output circuit type

Relay/FET

Pilot duty rating

Ordinary location – B300, R150, Hazardous location – C300, R150

Temperature, operating

-20…+65 °C (-4…+149 °F) ambient

Temperature, storage

-40…+85 °C (-40…+185 °F) ambient

Relative humidity

5%…95% noncondensing

Vibration

Operating: 10…500 Hz, 5 g, 0.015 in. max peak-to-peak, 2 hours each axis, Relay Operation: 1.5 g

Shock, operating

30 g; 3 pulses each direction, each axis, Relay Operation: 10 g

Shock, nonoperating

50 g panel mounted (40 g DIN Rail mounted); 3 pulses each direction, each axis

Terminal screw torque

0.56 Nm (5.0 lbin) rated

Agency certification

UL Listed Industrial Control Equipment for use in Class 1 Division 2, Hazardous Locations, Groups A, B, C, D

ESD immunity

EN 61000-4-2 4 kV contact, 8 kV air, 4 kV indirect

Radiated RF immunity

EN 61000-4-3 10V/m, 26…1000 MHz (alternatively, 80…1000 MHz), 80% amplitude modulation, +900 MHz keyed carrier

Fast transient immunity

EN 61000-4-4 2 kV, 5 kHz, Communications cables such as Ethernet, RS-232, and RS-485: 1 kV, 5 kHz

Surge transient immunity

EN 61000-4-5, Unshielded communications cable: 2 kV CM (common mode), 1 kV DM (differential mode), Shielded communications cable: 1 kV galvanic gun, I/O: 2 kV CM (common mode), 1 kV DM (differential mode), AC power supply input: 4 kV CM (common mode), 2 kV DM (differential mode), DC power supply input: 500V CM (common mode), 500V DM (differential mode), AC/DC auxiliary output: 500V CM (common mode), 500V DM (differential mode)

Conducted RF immunity

EN 61000-4-6 10V, 150 kHz…80 MHz

Conducted emissions

EN 55011, AC power supply input: 150 kHz…30 MHz

Radiated emissions

EN 55011 30…1000 MHz

Line related tests

EN 61000-4-11, AC power supply input:, Voltage drop: -30% for 10 ms, -60% for 100 ms, Voltage interrupt: at voltage greater than -95% for 5 s, Voltage fluctuation: +10% for 15 min, -10% for 15 min, DC power supply input:, Voltage fluctuation: +20% for 15 min, -20% for 15 min

Technical documents (1)

• Rockwell Automation user manual 1763-UM001

Key features

• 10 digital and 2 analog inputs
• Digital inputs 24V DC sinking/sourcing, standard and high-speed
• Analog inputs 0…10V DC with 10-bit resolution
• UL Listed for Class 1 Division 2, Groups A, B, C, D
• Operating ambient temperature of -20…+65 °C

About the Allen-Bradley 1763-L16BBB

The 1763-L16BBB is a MicroLogix 1100 16 point controller, now discontinued. It has 12 inputs (10 digital, 2 analog) and 6 relay/FET outputs, and runs from 24V DC (-15%, +10%), Class 2 SELV, using up to 35 W. It measures 90 x 110 x 87 mm (HxWxD) and has a shipping weight of 0.9 kg.

What is the 1763-L16BBB used for?

It controls a small machine with its I/O on board (user manual 1763-UM001). Digital inputs are 24V DC and analog inputs 0…10V DC. Pilot duty ratings are B300, R150 for ordinary locations and C300, R150 for hazardous locations.

Lifecycle and successor

Discontinued (Rockwell Automation lifecycle status, checked 25 October 2026).

Before you order

What to photograph or confirm so the right unit is quoted.

Read the catalog number 1763-L16BBB, the series letter and the firmware revision from the label. Send us a photo of the label and we confirm the match before we quote.
