DEIF AGC-3

Technical specifications

Manufacturer

DEIF

Manufacturer part no.

AGC-3

Type

Automatic genset controller

Application

Genset control / power management; marine use should be tied to variant/approval documentation

Used with

Generator sets / power-management systems

Product

AGC-3 automatic genset controller, DEIF Multi-line 2

Measuring voltage

100 to 690 V AC +/-20%

Measuring current

-/1 or -/5 A AC, from CTs

Measuring frequency

30 to 70 Hz

Current overload

4 x In continuously; 20 x In for 10 s (max. 75 A); 80 x In for 1 s (max. 300 A)

Auxiliary supply

12/24 V DC nominal (8 to 36 V DC operational), max. 11 W

Relay outputs

250 V AC / 30 V DC, 5 A

Communication options

Modbus RTU (RS-485), Profibus DP, CAN bus J1939 engine communication

Protection

Unit IP20; display IP40 (IP54 with gasket, option L)

Vibration

To IEC 60068-2-6 and IACS UR E10

Mounting

DIN rail or base mount with six screws

Weight

Base unit 1.6 kg; display 0.4 kg

Approvals

UL/cUL Listed to UL508

Technical documents (1)

• DEIF AGC-3 data sheet 4921240396

Key features

• Protection and control of one genset in a single unit
• Automatic mains failure, island, fixed power, peak shaving and load takeover
• Optional load sharing and power management
• Three-phase measuring with LCD display
• Modbus, Profibus and J1939 engine communication options
• DEIF: phased out and replaced by the AGC-4 Mk II

About the DEIF AGC-3

The DEIF AGC-3 is an automatic genset controller from DEIF's Multi-line 2 range: a compact unit with all the measuring, protection and control functions for one generator set, with values and alarms shown on its display. It covers automatic mains failure, island operation, fixed power, peak shaving, load takeover and mains export, and with options it handles load sharing and power management across several gensets. DEIF states that the AGC-3 has been phased out and replaced by the AGC-4 Mk II.

What is the AGC-3 used for?

The AGC-3 controls and protects a generator set: starting and stopping the engine, synchronising, closing the breaker and sharing load with other sets. When one fails in a running installation, an exact AGC-3 with the same options keeps the existing configuration; moving to the AGC-4 Mk II means reconfiguring the controller.

Lifecycle and successor

Discontinued.

OEM successor: AGC-4 Mk II

Before you order

What to photograph or confirm so the right unit is quoted.

Check the item number and variant on the label, the installed options, and the software version. Send a label photo and the vessel name or IMO number.
