DEIF AGC-4

Technical specifications

Manufacturer

DEIF

Manufacturer part no.

AGC-4

Type

Automatic genset controller

Application

Genset control and power management

Used with

Generator sets / multi-genset systems

Product

AGC-4 automatic genset controller, DEIF Multi-line 2

Controller types

Genset (DG), Mains, BTB, Group and Plant

Measuring voltage

100 to 690 V AC +/-20%

Measuring current

-/1 or -/5 A AC, from CTs

Measuring frequency

30 to 70 Hz

Current overload

4 x In continuously; 20 x In for 10 s (max. 75 A); 80 x In for 1 s (max. 300 A)

Auxiliary supply

12/24 V DC nominal (8 to 36 V DC operational), max. 11 W

Digital inputs

Optocoupler, bi-directional, ON at 8 to 36 V DC

Multi-inputs

0(4) to 20 mA, Pt100/Pt1000, RMI, V DC or digital

RPM input

Magnetic pickup, 2 to 70 V AC, 10 to 10000 Hz

Relay outputs

250 V AC / 30 V DC, 5 A

Analogue outputs

0(4) to 20 mA and +/-25 mA, galvanically separated

Operating temperature

-25 to 70 °C (-25 to 60 °C with Modbus TCP/IP option N)

Storage temperature

-40 to 70 °C

Protection

Controller IP20; DU-2 display IP40 (IP54 with gasket, option L)

Vibration

To IEC 60068-2-6 and IACS UR E10

Mounting

DIN rail or base mount with six screws

Weight

Controller 1.6 kg; DU-2 display 0.4 kg

Service port

USB A-B

Technical documents (1)

• DEIF AGC-4 data sheet 4921240400

Key features

• Genset, mains, bus tie and plant control in one hardware platform
• Power management for multiple gensets, including split and ring busbars
• Generator, busbar and mains protection
• Interfaces to governors and AVRs by analogue, relay or CAN J1939
• Separate DU-2 display, can be mounted in the switchboard door
• DEIF: being phased out, replaced by the AGC-4 Mk II

About the DEIF AGC-4

The DEIF AGC-4 is an automatic genset controller from DEIF's Multi-line 2 range. One unit handles a generator's protection, synchronising and breaker control, and several AGC-4 controllers can be linked into a complete power management system for island operation or operation parallel with the grid, including split and ring busbars. It measures three-phase voltage and current directly (100 to 690 V AC, 1 A or 5 A CTs) and drives the governor and AVR through analogue outputs, relays or a J1939 CAN link. DEIF states that the AGC-4 is being phased out and replaced by the AGC-4 Mk II; spare part units can still be delivered.

What is the AGC-4 used for?

On ships the AGC-4 is used in generator switchboards to start, stop, synchronise and load-share diesel generators, and to control bus tie and shore connection breakers. A replacement has to match the controller type (DG, Mains, BTB, Group or Plant), the option set and the software version of the unit being replaced, because the power management system is configured across all controllers in the plant.

Lifecycle and successor

Phased out.

OEM successor: AGC-4 Mk II

Before you order

What to photograph or confirm so the right unit is quoted.

Check the item number and variant on the label (for example 2912410040-xx), the controller type (DG, Mains, BTB, Group or Plant) and the installed options, and note the software version shown in the display or utility software. Send a label photo and the vessel name or IMO number.
