HARTING 09 33 006 2601

Technical specifications

Manufacturer

HARTING

Manufacturer part no.

09 33 006 2601

Type

Heavy-duty connector insert

Application

Heavy-duty machine and panel connectors

Used with

Han B size 6 B hoods and housings; Han E 6 female insert 09 33 006 2701

Category

Inserts

Series

Han E®

Termination method

Screw termination

Gender

Male

Size

6 B

With wire protection

Yes

Number of contacts

6

PE contact

Yes

Conductor cross-section (mm²)

0.75 ... 2.5 mm²

Conductor cross-section (AWG)

AWG 18 ... AWG 14

Rated voltage acc. to CSA

600 V

Rated current

16 A

Rated voltage

500 V

Rated impulse voltage

6 kV

Pollution degree

3

Rated voltage acc. to UL

600 V

Insulation resistance

> 10¹⁰ Ω

Contact resistance

≤ 1 mΩ

Limiting temperature

-40 ... +125 °C

Stripping length

7.5 mm

Tightening torque

0.5 Nm Contact screw M3; 0.5 Nm Fixing screws M3; 1.2 Nm PE screw M4

Recommended screw driver

Slotted 0.6 x 3.5; Slotted 0.8 x 4.5; PH2

Mating cycles

≥ 500

Material (insert)

Polycarbonate (PC)

Colour (insert)

RAL 7032 (pebble grey)

Technical documents (1)

• HARTING product page 09 33 006 2601

Key features

• 6 pin contacts plus a PE contact
• Screw termination, 0.75 to 2.5 mm² (AWG 18 to 14)
• 16 A, 500 V, 6 kV rated impulse voltage
• Silver-plated copper alloy contacts in a polycarbonate insert
• DNV GL approval; UL and CSA 600 V

About the HARTING 09 33 006 2601

The HARTING 09 33 006 2601 is the male (pin) insert of a Han E 6 connector. It mates with the female insert 09 33 006 2701, and the two differ only in gender. HARTING rates it at 16 A and 500 V, 600 V to UL and CSA, with a 6 kV rated impulse voltage at pollution degree 3. Wires of 0.75 to 2.5 mm² clamp directly under M3 screws, stripped to 7.5 mm, and wire protection is built in. It fits a size 6 B Han B hood or housing.

What is the 09 33 006 2601 used for?

It is the pin side of a 6-pole power and control connection on a machine or panel, usually fitted in the bulkhead housing so the live side is the female insert in the cable hood. Typical uses are motor and heater feeds between machine modules.

Lifecycle and successor

Active.

Before you order

What to photograph or confirm so the right unit is quoted.

HARTING prints the article number 09 33 006 2601 on the insert. Check it is the male (pin) version and screw termination: the crimp version is 09 33 006 2602.
