Mitsubishi Electric Q00UJCPU

Technical specifications

Manufacturer

Mitsubishi Electric

Manufacturer part no.

Q00UJCPU

Type

MELSEC-Q CPU module

Application

PLC controller

Used with

MELSEC-Q base units

Control method

Stored program cyclic operation

I/O control mode

Refresh mode; (The direct access input/output is available by specifying the direct access input/output (DX, DY).)

Programming language, Sequence control language

Relay symbol language, logic symbolic language, MELSAP3 (SFC), MELSAP-L, function block and structured text (ST)

Processing speed, Sequence instruction, LD X0

120 ns

Processing speed, Sequence instruction, MOV D0 D1

240 ns

Constant scan

0.5...2000 ms (setting is available in increments of 0.5 ms by parameter)

Program capacity

10K steps (40K bytes)

Memory capacity, Program memory (drive 0)

40K bytes

Memory capacity, Standard ROM (drive 4)

256K bytes

Number of I/O device points

8192 points (X/Y0...1FFF)

Number of I/O points

256 points (X/Y0...FF)

RUN/PAUSE contact

One contact can be set up in X0 to X1FFF for each of RUN and PAUSE.

Clock function

Year, month, date, hour, minute, second, and day of week (automatic leap year detection); Accuracy: -2.96...+3.74 s (TYP. +1.24 s)/d at 0 ˚C; Accuracy: -2.34...+3.74 s (TYP. +1.63 s)/d at 25 ˚C; Accuracy: -11.48...+2.12 s (TYP. -3.03 s)/d at 55 ˚C

Allowable momentary power failure time

Within 20 ms (100 V AC or more)

Internal current consumption (5 V DC)

0.37 A

External dimensions, Height

98 mm

External dimensions, Width

245 mm

External dimensions, Depth

98 mm

Weight

0.70 kg

Input power supply voltage

100...240 V AC (-15 %...+10 %)

Input frequency

50/60 Hz ±5 %

Input voltage distortion

Within 5 %

Maximum input apparent power

105 VA

Inrush current

40 A, within 8 ms

Rated output current, 5 V DC

3 A

Technical documents (1)

• Mitsubishi Electric specification database, Q00UJCPU

Key features

• Program memory: 40K bytes
• Current consumption (5 V DC): 0.37 A
• Weight: 0.70 kg

About the Mitsubishi Electric Q00UJCPU

The Mitsubishi Electric Q00UJCPU is a MELSEC-Q CPU module. Mitsubishi Electric's overview: Number of I/O points: 256, number of I/O device points: 8192, program size: 10K steps, processing speed (LD X0): 120 ns, program size: 40K bytes, peripheral connection ports: USB/RS-232, without memory card interface, base: 5 slots, power supply: 100...240 V AC input/5 V DC 3A output.

What is the Q00UJCPU used for?

The Q00UJCPU runs the control program on a MELSEC-Q base unit, working with the I/O, intelligent function and network modules on the base.

Lifecycle and successor

Phased out.

Before you order

What to photograph or confirm so the right unit is quoted.

Check the model name Q00UJCPU on the rating plate, with the serial number and function version. Send us a photo of the rating plate and we will confirm the details before quoting.
