Siemens 6ES7421-1EL00-0AA0

SM 421 digital input, 32 DI, 120 V AC/DC

Read from the product label

Maker: Siemens
Part no.: 6ES7421-1EL00-0AA0
Serial / rev.: as printed on your unit

Image is for illustrative purposes only. Please refer to product description.

Delivery options

Siemens SIMATIC S7-400 SM 421 digital input module: 32 isolated inputs for 120 V AC or DC, in groups of 8.

Manufacturer: Siemens
Manufacturer part no.: 6ES7421-1EL00-0AA0
Product family: SIMATIC S7-400 PLC CPUs, I/O and Function Modules
Type: Digital input module
Category: PLCs and I/O › Digital I/O modules
Lifecycle: Discontinued
OEM successor: Not stated
Technical datasheet: Data sheet

Technical specifications

Manufacturer: Siemens
Manufacturer part no.: 6ES7421-1EL00-0AA0
Type: Digital input module
Application: Digital input module
Used with: SIMATIC S7-400 rack
Input current / from backplane bus 5 V DC, max.: 200 mA
Power loss, typ.: 6.5 W
Number of digital inputs: 32
Digital inputs / Input characteristic according to IEC 61131: Type 1
Number of simultaneously controllable inputs / Number of simultaneously controllable inputs: 32
Input voltage / Type of input voltage: AC/DC
Input voltage / Rated value (UC): 120 V; 47 ... 63 Hz
Input voltage / for signal "0": 0 to 20 V UC
Input voltage / for signal "1": 79 to 132 V AC; 80 to 132 V DC
Input current / for signal "0", min.: 0 mA
Input current / for signal "0", max. (permissible quiescent current): 1 mA
Input current / for signal "1", typ.: 2 mA; 2 to 5 mA
Input delay (for rated value of input voltage) / for standard inputs / at "0" to "1", min.: 5 ms
Input delay (for rated value of input voltage) / for standard inputs / at "0" to "1", max.: 25 ms; 10 / 20 ms
Input delay (for rated value of input voltage) / for standard inputs / at "1" to "0", min.: 5 ms
Input delay (for rated value of input voltage) / for standard inputs / at "1" to "0", max.: 25 µs
Cable length / shielded, max.: 1 000 m
Cable length / unshielded, max.: 600 m
Connectable encoders / 2-wire sensor: Yes
Connectable encoders / 2-wire sensor / permissible quiescent current (2-wire sensor), max.: 1 mA
Diagnostics indication LED / Status indicator digital input (green): Yes
Potential separation digital inputs / between the channels: Yes
Potential separation digital inputs / between the channels, in groups of: 8
Potential separation digital inputs / between the channels and backplane bus: Yes
Isolation tested with: 1 500 V AC

Show all 34 specifications

Width: 25 mm
Height: 290 mm
Depth: 210 mm
Weight, approx.: 600 g

Technical documents (1)

Siemens data sheet 6ES7421-1EL00-0AA0

Key features

32 digital inputs, 120 V AC (47 to 63 Hz) or DC
Signal "1" at 79 to 132 V AC or 80 to 132 V DC
Isolated in groups of 8
Input delay up to 25 ms
Discontinued by Siemens on 1 October 2026

About the Siemens 6ES7421-1EL00-0AA0

The Siemens 6ES7421-1EL00-0AA0 is the 120 V version of the 32-channel SM 421: it reads AC or DC signals at 120 V where the 6ES7421-1BL01-0AA0 reads 24 V DC. Siemens's data sheet gives signal "1" at 79 to 132 V AC or 80 to 132 V DC, 2 to 5 mA input current, isolation in groups of 8 and 6.5 W typical power loss. SiePortal shows its phase-out announced on 1 October 2025 and its product cancellation on 1 October 2026.

What is the 6ES7421-1EL00-0AA0 used for?

It reads 120 V AC or DC signals from switches and contacts into an S7-400 CPU.

Lifecycle and successor

Discontinued.
