ABB 3BSE020510R1 DO801

Technical specifications

Manufacturer

ABB

Manufacturer part no.

3BSE020510R1

Type

Digital output module

Application

Switches discrete field outputs according to controller commands.

Used with

S800L process I/O; confirm connection and controller configuration.

Module model

DO801

Article number

3BSE020510R1

Type

Digital Output

Number of channels

16

Signal specification

24 V d.c. (12 - 32 V d.c.), 0.5 A

Signal type

Current sourcing, current limiting

HART

No

SOE

No

Redundancy

No

High integrity

No

Intrinsic safety

No

Isolation

Groupwise isolated from ground

Output load

< 0.4 Ω

Current limiting

Short circuit proof current limited output

Power dissipation

Typ. 2.1 W

Current consumption +5 V Modulebus

80 mA

Current consumption +24 V Modulebus

0

Current consumption +24 V external

0

Temperature, Operating

0 to +55 °C (+32 to +131 °F), approvals are issued for +5 to +55 °C

Temperature, Storage

-40 to +70 °C (-40 to +158 °F)

Relative humidity

5 to 95 %, non-condensing

Protection class

IP20 according to IEC 60529

Width

86.1 mm

Height

110 mm

Depth

58.5 mm

Technical documents (1)

• ABB DO801 technical data and PDF export

Key features

• 16 digital output channels
• Signal range: 24 V d.c. (12 - 32 V d.c.), 0.5 A
• Isolation: Groupwise isolated from ground
• Redundancy: No
• HART: No

About the ABB 3BSE020510R1

DO801 (3BSE020510R1) is an ABB S800L digital output module with 16 channels. Signal specification: 24 V d.c. (12 - 32 V d.c.), 0.5 A. The module uses the S800L mechanical format. ABB lists groupwise isolated from ground isolation. Order number 3BSE020510R1 identifies this module variant; the model name and revision should be checked together before replacement.

What is the 3BSE020510R1 used for?

Switches discrete field outputs according to controller commands.

Lifecycle and successor

To be confirmed.

Before you order

What to photograph or confirm so the right unit is quoted.

Confirm both DO801 and order number 3BSE020510R1, hardware revision, installed controller and I/O configuration. Match signal range, channel wiring, termination unit and keying. Confirm redundancy or safety requirements against the OEM system documentation; related modules are not automatically interchangeable.
