ABB 3BSE020512R1 AI801

Technical specifications

Manufacturer

ABB

Manufacturer part no.

3BSE020512R1

Type

Analog input module

Application

Acquires analogue field signals for process monitoring and control.

Used with

S800L process I/O; confirm connection and controller configuration.

Module model

AI801

Article number

3BSE020512R1

Type

Analog Input

Number of channels

8

Signal specification

0...20 mA, 4...20 mA

Signal type

Unipolar single ended

Resolution

12 bit

HART

No

SOE

No

Redundancy

No

High integrity

No

Intrinsic safety

No

Isolation

Groupwise isolated from ground

Update cycle time

1 ms

Power dissipation

1.1 W

Current consumption +5 V Modulebus

70 mA

Current consumption +24 V Modulebus

0

Current consumption +24 V external

30 mA

Temperature, Operating

0 to +55 °C (+32 to +131 °F), approvals are issued for +5 to +55 °C

Temperature, Storage

-40 to +70 °C (-40 to +158 °F)

Relative humidity

5 to 95 %, non-condensing

Protection class

IP20 according to IEC 60529

Width

86.1 mm

Height

110 mm

Depth

58.5 mm

Technical documents (1)

• ABB AI801 technical data and PDF export

Key features

• 8 analog input channels
• Signal range: 0...20 mA, 4...20 mA
• Resolution: 12 bit
• Isolation: Groupwise isolated from ground
• Redundancy: No
• HART: No

About the ABB 3BSE020512R1

AI801 (3BSE020512R1) is an ABB S800L analog input module with 8 channels. Signal specification: 0...20 mA, 4...20 mA. The module uses the S800L mechanical format. The specified resolution is 12 bit. ABB lists groupwise isolated from ground isolation. Order number 3BSE020512R1 identifies this module variant; the model name and revision should be checked together before replacement.

What is the 3BSE020512R1 used for?

Acquires analogue field signals for process monitoring and control.

Lifecycle and successor

To be confirmed.

Before you order

What to photograph or confirm so the right unit is quoted.

Confirm both AI801 and order number 3BSE020512R1, hardware revision, installed controller and I/O configuration. Match signal range, channel wiring, termination unit and keying. Confirm redundancy or safety requirements against the OEM system documentation; related modules are not automatically interchangeable.
