ABB 3BSE020514R1 AO801

Technical specifications

Manufacturer

ABB

Manufacturer part no.

3BSE020514R1

Type

Analog output module

Application

Provides analogue commands from the control system to field equipment.

Used with

S800L process I/O; confirm connection and controller configuration.

Module model

AO801

Article number

3BSE020514R1

Type

Analog Output

Number of channels

8

Signal specification

0... 20 mA, 4...20 mA

Signal type

Unipolar single ended

Resolution

12 bit

HART

No

SOE

No

Redundancy

No

High integrity

No

Intrinsic safety

No

Isolation

Groupwise isolated from ground

Output load

Max 850 Ω

Current limiting

Short circuit proof current limited output

Update cycle time

1 ms

Power dissipation

3.8 W

Current consumption +5 V Modulebus

70 mA

Current consumption +24 V Modulebus

-

Current consumption +24 V external

200 mA

Temperature, Operating

0 to +55 °C (+32 to +131 °F), approvals are issued for +5 to +55 °C

Temperature, Storage

-40 to +70 °C (-40 to +158 °F)

Relative humidity

5 to 95 %, non-condensing

Protection class

IP20 according to IEC 60529

Width

86.1 mm

Technical documents (1)

• ABB AO801 technical data and PDF export

Key features

• 8 analog output channels
• Signal range: 0... 20 mA, 4...20 mA
• Resolution: 12 bit
• Isolation: Groupwise isolated from ground
• Redundancy: No
• HART: No

About the ABB 3BSE020514R1

AO801 (3BSE020514R1) is an ABB S800L analog output module with 8 channels. Signal specification: 0... 20 mA, 4...20 mA. The module uses the S800L mechanical format. The specified resolution is 12 bit. ABB lists groupwise isolated from ground isolation. Order number 3BSE020514R1 identifies this module variant; the model name and revision should be checked together before replacement.

What is the 3BSE020514R1 used for?

Provides analogue commands from the control system to field equipment.

Lifecycle and successor

To be confirmed.

Before you order

What to photograph or confirm so the right unit is quoted.

Confirm both AO801 and order number 3BSE020514R1, hardware revision, installed controller and I/O configuration. Match signal range, channel wiring, termination unit and keying. Confirm redundancy or safety requirements against the OEM system documentation; related modules are not automatically interchangeable.
