Siemens 6ES7153-4AA01-0XB0

Technical specifications

Manufacturer

Siemens

Manufacturer part no.

6ES7153-4AA01-0XB0

Type

Interface module

Application

PROFINET IO interface for ET 200M

Used with

ET 200M station on PROFINET IO

Product type designation

IM 153-4 PN ST

Vendor identification (VendorID)

002AH

Device identifier (DeviceID)

0302H

Supply voltage / Rated value (DC)

24 V

Supply voltage / permissible range, lower limit (DC)

20.4 V

Supply voltage / permissible range, upper limit (DC)

28.8 V

external protection for power supply lines (recommendation)

In a construction with grounded reference potential, a fuse is necessary for redundant interface modules (Recommendation: 2.5 A)

Mains buffering / Mains/voltage failure stored energy time

5 ms

Input current / Current consumption, max.

600 mA; with 24 V DC supply

Input current / Inrush current, typ.

4 A

Input current / I²t

0.09 A²·s

Output voltage / Rated value (DC)

5 V

Output current / for backplane bus (5 V DC), max.

1.5 A

Power loss, typ.

6 W

Address space per module / Inputs

192 byte

Address space per module / Outputs

192 byte

Hardware configuration / number of modules per DP device interface, max.

12

Protocols / Bus protocol/transmission protocol

PROFINET IO

Protocols (Ethernet) / TCP/IP

No

Redundancy mode / PROFINET system redundancy (S2)

No

Redundancy mode / Media redundancy / MRP

Yes

Diagnostics indication LED / LINK LED

Yes; green LED

Diagnostics indication LED / RX/TX LED

Yes; Yellow LED

Diagnostics indication LED / for module diagnostics

Yes

Potential separation exists

Yes

Technical documents (1)

• Siemens data sheet 6ES7153-4AA01-0XB0

Key features

• PROFINET IO interface for an ET 200M station
• Up to 12 S7-300 modules, 192 bytes of inputs and 192 bytes of outputs
• Media redundancy (MRP)
• Isochronous real-time, module exchange without a programming device, operation without a Micro Memory Card (Siemens's description)
• Discontinued by Siemens on 1 October 2024; spare part only

About the Siemens 6ES7153-4AA01-0XB0

The Siemens 6ES7153-4AA01-0XB0 is the PROFINET version of the ET 200M interface module: where the IM 153-1 and IM 153-2 connect an ET 200M station to PROFIBUS DP, the IM 153-4 PN connects it to PROFINET IO. Siemens's data sheet gives up to 12 S7-300 modules, 192 bytes each of inputs and outputs, media redundancy (MRP), a 24 V DC supply (20.4 to 28.8 V) and up to 1.5 A for the backplane bus. SiePortal shows its product cancellation on 1 October 2024, a year before most of the S7-300 range, and siemens's data sheet marks it as a spare part.

What is the 6ES7153-4AA01-0XB0 used for?

It is the head of an ET 200M remote I/O station on PROFINET: it passes the S7-300 modules' inputs and outputs to the PROFINET IO controller.

Lifecycle and successor

Discontinued.

Before you order

What to photograph or confirm so the right unit is quoted.

Check the full order number and firmware version on the module. The IM 153-4 PN is for PROFINET; the IM 153-1 and IM 153-2 are for PROFIBUS DP.
