6ES7193-6AR00-0AA0

Technical specifications

Manufacturer

Siemens

Manufacturer part no.

6ES7193-6AR00-0AA0

Type

BusAdapter

Application

PROFINET connection for ET 200SP interface modules

Used with

ET 200SP interface modules with a BusAdapter slot

Product type designation

BA 2x RJ45

Number of PROFINET interfaces

1; 2 ports (switch) 2x RJ45

Supports protocol for PROFINET IO / Number of RJ45 ports

2

Supports protocol for PROFINET IO / Cable length / Cu conductors

100 m

Ecological footprint / environmental product declaration

Yes

Ecological footprint / Global warming potential / global warming potential, (total) [CO2 eq]

1.14 kg

Ecological footprint / Global warming potential / global warming potential, (during production) [CO2 eq]

1.2 kg

Ecological footprint / Global warming potential / global warming potential, (during operation) [CO2 eq]

0 kg

Ecological footprint / Global warming potential / global warming potential, (after end of life cycle) [CO2 eq]

-0.069 kg

Ambient temperature during operation / horizontal installation, min.

-30 °C

Ambient temperature during operation / horizontal installation, max.

60 °C

Ambient temperature during operation / vertical installation, min.

-30 °C

Ambient temperature during operation / vertical installation, max.

50 °C

Altitude during operation relating to sea level / Installation altitude above sea level, max.

5 000 m; restrictions for installation altitudes > 2 000 m, see ET 200SP system manual

Absolute humidity / dew point, min.

-60 °C; suitable for dry room applications

Width

20 mm

Height

69.5 mm

Depth

59 mm

Weight, approx.

46 g

Technical documents (1)

• Siemens data sheet 6ES7193-6AR00-0AA0

Key features

• Two RJ45 sockets
• Plugs into ET 200SP interface modules with a BusAdapter slot
• Two-port PROFINET connection (switch)

About the Siemens 6ES7193-6AR00-0AA0

The Siemens 6ES7193-6AR00-0AA0 is the BusAdapter BA 2xRJ45: the plug-in connector block that gives an ET 200SP interface module its two PROFINET RJ45 sockets. SiePortal lists it as an active product.

What is the 6ES7193-6AR00-0AA0 used for?

It sits on the front of an IM 155-6 PN interface module and takes the incoming and outgoing PROFINET cables, so the station can sit in a line topology.

Lifecycle and successor

Active product (Siemens SiePortal).

Before you order

What to photograph or confirm so the right unit is quoted.

Check the order number on the BusAdapter: this one has two RJ45 sockets.
