Siemens 6ES7451-3AL00-0AE0

FM 451 positioning module, 3 channels, rapid/creep traverse

Image is for illustrative purposes only. Please refer to product description.

Delivery options

Siemens SIMATIC S7-400 FM 451 positioning module for rapid/creep traverse drives: 3 channels, incremental or SSI encoders, configuration package on CD.

Manufacturer: Siemens
Manufacturer part no.: 6ES7451-3AL00-0AE0
Product family: SIMATIC S7-400 PLC CPUs, I/O and Function Modules
Type: Positioning module
Category: PLCs and I/O › Counter, positioning and temperature modules
Lifecycle: Discontinued
OEM successor: Not stated
Technical datasheet: Data sheet

Technical specifications

Manufacturer: Siemens
Manufacturer part no.: 6ES7451-3AL00-0AE0
Type: Positioning module
Application: Positioning module
Used with: SIMATIC S7-400 rack
Supply voltage / Rated value (DC): 24 V
Input current / Current consumption, typ.: 550 mA
5 V encoder supply / 5 V: Yes
5 V encoder supply / Output current, max.: 210 mA
5 V encoder supply / Cable length, max.: 35 m; at max. 210 mA
24 V encoder supply / 24 V: Yes
24 V encoder supply / Output current, max.: 300 mA
24 V encoder supply / Cable length, max.: 100 m; at max. 300 mA
Absolute encoder (SSI) encoder supply / Absolute encoder (SSI): Yes
Absolute encoder (SSI) encoder supply / Type of output voltage: 24 V DC
Absolute encoder (SSI) encoder supply / Output current, max.: 300 mA
Absolute encoder (SSI) encoder supply / Cable length, max.: 300 m; At max. 156 kbit/s
Power loss, typ.: 3.6 W
Number of digital inputs: 12; 4 per axis
Digital inputs / Functions: Reference cams, reversing cams, flying actual value setting, start/stop positioning
Input voltage / Rated value (DC): 24 V
Input voltage / for signal "0": -30 to +5 V
Input voltage / for signal "1": +11 to +30V
Input current / for signal "0", max. (permissible quiescent current): 1.5 mA
Input current / for signal "1", typ.: 9 mA
Number of digital outputs: 12; 4 per axis
Digital outputs / Functions: Rapid traverse, creep, run right, run left
Digital outputs / Short-circuit protection: Yes
Output voltage / for signal "1", min.: UP -3 V
Output current / for signal "1" permissible range for 0 to 55 °C, max.: 600 mA; with UPmax

Show all 61 specifications

Output current / for signal "0" residual current, max.: 0.5 mA
Connectable encoders / Incremental encoder (symmetrical): Yes
Connectable encoders / Incremental encoder (asymmetrical): Yes
Connectable encoders / Absolute encoder (SSI): Yes
Encoder signals, incremental encoder (symmetrical) / Trace mark signals: A, notA, B, notB
Encoder signals, incremental encoder (symmetrical) / Zero mark signal: N, notN
Encoder signals, incremental encoder (symmetrical) / Input voltage: 5 V difference signal (phys. RS 422)
Encoder signals, incremental encoder (symmetrical) / Input frequency, max.: 1 MHz
Encoder signals, incremental encoder (asymmetrical) / Trace mark signals: A, B
Encoder signals, incremental encoder (asymmetrical) / Zero mark signal: N
Encoder signals, incremental encoder (asymmetrical) / Input voltage: 24 V
Encoder signals, incremental encoder (asymmetrical) / Input frequency, max.: 50 kHz; for 25 m cable length, 25 kHz for 100 m cable length
Encoder signals, incremental encoder (asymmetrical) / Cable length, shielded, max.: 100 m
Encoder signals, absolute encoder (SSI) / Input signal: 5 V difference signal (phys. RS 422)
Encoder signals, absolute encoder (SSI) / Data signal: DATA, notDATA
Encoder signals, absolute encoder (SSI) / Clock signal: CL, notCL
Encoder signals, absolute encoder (SSI) / Telegram length, parameterizable: 13 or 25 bit serial
Encoder signals, absolute encoder (SSI) / Clock frequency, max.: 1.25 MHz
Encoder signals, absolute encoder (SSI) / Gray code: Yes
Encoder signals, absolute encoder (SSI) / Cable length, shielded, max.: 300 m; At max. 156 kbit/s
Potential separation digital inputs / Potential separation digital inputs: Yes
Potential separation digital outputs / Potential separation digital outputs: Yes
Ambient temperature during operation / min.: 0 °C
Ambient temperature during operation / max.: 55 °C
Ambient temperature during storage/transportation / min.: -40 °C
Ambient temperature during storage/transportation / max.: 70 °C
required front connector: 1x 48-pin
Width: 50 mm
Height: 290 mm
Depth: 210 mm
Weight, approx.: 1 300 g

Technical documents (1)

Siemens data sheet 6ES7451-3AL00-0AE0

Key features

3 positioning channels for drives with a rapid and a creep speed
4 digital inputs and 4 digital outputs per axis
Incremental encoders up to 1 MHz or SSI absolute encoders
5 V, 24 V and SSI encoder supplies
Discontinued by Siemens on 1 October 2026

About the Siemens 6ES7451-3AL00-0AE0

The Siemens 6ES7451-3AL00-0AE0 is the FM 451, the S7-400 positioning module for drives that run at a rapid and a creep speed, with 3 channels. Siemens's data sheet gives 4 digital inputs (reference cams, reversing cams, flying actual value setting, start/stop) and 4 digital outputs (rapid traverse, creep, run right, run left) per axis, incremental encoders up to 1 MHz or SSI absolute encoders, a 50 mm wide housing and 3.6 W typical power loss. SiePortal shows its phase-out announced on 1 October 2025 and its product cancellation on 1 October 2026.
