GPU 300

Technical specifications

Manufacturer

DEIF

Manufacturer part no.

GPU 300

Type

Generator protection unit

Application

Marine/offshore protection systems

Used with

Generator and busbar protection systems

Function

Generator protection unit: protects electrical equipment with a breaker, such as a diesel generator, busbar or motor

Breaker functions

Breaker trip and alarms, synchronisation check, breaker close (external command), breaker position detection

Non-essential load groups

Up to three

Voltage measurement

100 to 690 V AC phase-to-phase nominal (range 2 to 897 V AC); class 0.2

Current measurement

1 or 5 A AC from current transformer; class 0.2

Supply voltage

12 or 24 V DC nominal (8 to 36 V DC continuously)

Display

5-inch colour graphic display unit

Communication

Ethernet (IPv4 and IPv6) to display unit, PICUS and Modbus

Counters

Active power, reactive power, running hours, breaker trips

Logic

CustomLogic (ladder logic and function blocks)

Construction

Modular rack; up to three additional IOM3.1 I/O modules

Ingress protection

IP20 (all slots fitted)

Operating temperature

Rack and modules -40 to 70 °C; display unit -20 to 70 °C

Humidity

97% RH (IEC 60068-2-30)

Operating altitude

Up to 4000 m

Technical documents (1)

• DEIF GPU 300 data sheet (4921240530)

Key features

• Protection for a generator, busbar or motor breaker
• Synchronisation check before breaker close
• Class 0.2 voltage and current measurement up to 690 V AC
• Up to three non-essential load groups
• 5-inch colour display and CustomLogic
• Modular rack with up to three extra I/O modules

About the DEIF GPU 300

The DEIF GPU 300 is a generator protection unit from DEIF's Multi-line 300 platform, designed for marine use. Each controller contains the functions needed to protect electrical equipment with a breaker, such as a diesel generator, a busbar or a motor, with breaker trip and alarms, synchronisation check and breaker position detection. It measures three-phase voltage and current to class 0.2, can shed up to three non-essential load groups, and is configured through its 5-inch colour display or DEIF's PICUS software. DEIF lists the GPU 300 as not recommended for new designs and names the iE 250 as its successor.

What is the GPU 300 used for?

The GPU 300 is fitted in marine switchboards to protect a generator breaker, and can also disconnect up to three groups of non-essential loads.

Lifecycle and successor

Not recommended for new designs / being phased out.

OEM successor: iE 250

Before you order

What to photograph or confirm so the right unit is quoted.

Check the order code and variant on the rack label, the number of IOM3.1 I/O modules fitted, and the display unit type. Send a label photo and, if available, a PICUS configuration backup.
